NORD MODULAR G2 V1.4x 13. Module reference: LFO group
Page 187
LFO GROUP
LFOs or Low Frequency Oscillator modules are used to create varying control signals for periodic
modulations. The waveforms they produce can be used for vibrato, tremolo or as clock sources. Some
of the LFOs in Nord Modular G2 have a very wide frequency range, from very low to frequencies in the
audio range.
C
OMMON
LFO
PARAMETERS
W
AVEFORM
RADIO
BUTTONS
LFO A, B and ShpA have waveform selectors of radio button type. All waveforms
in these LFOs are instantly available by clicking the desired waveform button.
W
AVEFORM
DROP
-
DOWN
SELECTORS
LFO C has a drop-down waveform selector. The different waveforms of LFO C are not instantly
available as in the “radio button” LFO described above. The advantage of this is that LFO C uses
less Patch Load. However, changing waveform in LFO C will force the Sound engine to
recalculate and thus cause a brief moment of silence. So if you’re looking for lower Patch Load, use this
LFO instead of the “radio button” one.
W
AVEFORM
GRAPH
LFO B and ShpA have graphical display of the waveform with phase and shape (LFO ShpA).
The yellow number to the bottom left indicates the current Phase setting in degrees.
R
ATE
L
O
/R
ATE
H
I
/BPM/C
LK
/R
ATE
S
UB
SCROLL
BUTTON
Selects one of three ranges of the LFO rate: Rate Lo (normal), Rate Hi and Rate Sub, plus BPM
and Master Clock Sync mode. The Rate Lo range is from 62.9 secs/cycle to 24.4 Hz, the Rate
Hi range is from 0.26 Hz to 392 Hz, the Rate Sub range is from 699 secs/cycle 5.46 secs/cycle. The BPM
range is from 24 to 214. The Clk sync mode automatically locks on to the synth’s Master Clock and here
you set the intervals between 64:1 and 1:64T. The ‘T’ (triplet) indicates that the note value is 4/3 times
the original note value and the ‘D’ (dotted) indicates that the note value is 3/2 times the original note
value.
Note that the Clk sync mode is only available in the LfoB and LfoShpA modules.
R
ATE
Set the rate of the LFO with the knob. The Output LED will show you an approximation of
the rate, while the display box will indicate the exact frequency in Hertz, seconds, BPM or Sync
factor.
P
HASE
Set the phase of the LFO signal. The phase is shown, in degrees, in the Display Box and also
in the Graph. The phase can also me modulated from an external source. The modulation
amount can be attenuated with the knob of [Attenuator Type I].
P
ITCH
MODULATION
INPUT
There are one or more C
ONTROL
signal inputs for a modulation source to control the pitch of
the LFO. There can also be a modulation attenuator next to the input of [A
TTENUATOR
T
YPE
II].
