NORD MODULAR G2 V1.4x 13. Module reference: Oscillator group
Page 179
Double Saw signal. At 50% Shape setting, the signal consists of two Sawtooth waves in phase with each
other, at 75% two Sawtooth waves slightly phase shifted and at 99% two Sawtooth waves 90 degrees
phase shifted. When the Shape is modulated with negative values, the signal is “mirrored”.
Pulse is a Pulse with selectable
ASYMMETRIC
pulse width. This is the type of pulse waveform found in
most analog synthesizers. At 50% Shape setting, the signal is a perfect Square, at 75% a Pulse with 25%/
75% pulse width and at 99% a Pulse with 1%/99% pulse width. When the Shape is modulated with
negative values, the signal is “mirrored”.
SymPulse is a Pulse with selectable
SYMMETRIC
pulse width. At 50% Shape setting, the signal is a perfect
Square, at 75% a Pulse with 25% symmetric pulse width and at 99% a Pulse with 1% symmetric pulse
width. When the Shape is modulated with negative values, the signal is “mirrored”. If this waveform is
modulated with a triangle Lfo waveform it produces a nice ‘raw’ type of PWM sound. See also "Common
Oscillator parameters”.
S
HAPE
O
SCILLATOR
TIPS
With the Shape Oscillators A and B it’s very easy to
create an “analog style” sound without using a Filter.
Connect the OscShpB module according to the picture,
select the Sine1 waveform and assign the Shape knob to
an A
SSIGNABLE
K
NOB
. Play on the keyboard and turn
the A
SSIGNABLE
K
NOB
to increase the overtone
content. The effect is very similar to running a sawtooth
wave into a filter and increasing the Filter Cutoff
Frequency value.
O
SC
D
UAL
The Dual Oscillator produces pulse and sawtooth
waveforms and a suboctave with a square waveform.
Three mixer knobs set the blend of the three waveforms
on the output of the oscillator. The pulse width of the
pulse oscillator and the phase of the sawtooth signal can
be modulated. The Soft button reduces the overtone
content of the suboctave, making the suboctave sound warmer. See also "Common Oscillator
parameters”.
