13. Module reference: Note group NORD MODULAR G2 V1.4x
Page 168
G
LIDE
This module will smooth or slew sudden transitions in
level of a control signal. This will create a glide effect
between ‘jumping’ values in a control signal, similar to
the portamento effect. You can think of this module as a lowpass filter for control signals. The glide
effect can be linear (which will produce a longer glide time if the input signal value makes a bigger jump
in value) or logarithmic (basically the same glide time for smaller and bigger jumps in input value).
Tip! To make a legato introduced portamento on notes played on the G2 keyboard, it is often more
convenient to use the Keyboard Glide function in the Patch|Patch Settings window as described at
“Glide” on page 118.
G
LIDE
ON
Patch a high logic signal here to activate the gliding transition between the input signal levels (if the Glide
button is off). If no connection is made, the portamento can be controlled with the Glide button.
S
HAPE
Select ‘Lin’ (different time depending on the range between adjacent
input values) or ‘Log (basically the same time regardless of the range
between adjacent input values).
T
IME
Sets the transition (glide) time with the knob.
Log Range: 0.2 msec to 22.4 sec.
Lin Range: 0.2 msec/octave to about 23.5 seconds/octave
I
N
The blue control signal input.
O
UTPUT
Signal: Bipolar.
P
ITCH
T
RACK
The Pitch Tracker module can transform the pitch of a
monophonic audio input signal into a blue control signal
on the Pitch output. The output control signal can be
patched directly into a Pitch input of an oscillator or filter. The module features a Gate function with
selectable threshold which produces a logic
HIGH
signal when the input level exceeds the Threshold
value.
The Pitchtrack module uses an advanced tracking method that is a good trade off between speed, noise
immunity and accuracy.
I
NPUT
The input of the PitchTrack module.
P
ERIOD
Outputs a very short logic
HIGH
pulse every time a new pitch measurement value is available.
Signal: L
OGIC
.
Shape Log Shape Lin
