NORD MODULAR G2 V1.4x 13. Module reference: Note group
Page 165
C
APTURE
Select ‘Evenly’ with this button to force the module to “split up” the key quantization grid in equally big
sections per octave.
I
N
The Range control signal input.
O
UT
Signal: Bipolar.
E
XAMPLE
The example below shows the principle for creating a simple arpeggiator. LFO A is set to generate a
triangle wave, since this signal has linear, symmetrical ramps. This guarantees even change of control
values over time. Press four Note buttons on the module’s mini-keyboard and selected a Range of +/-
32 semitones on the KeyQuant module. The output signal from the KeyQuant module is routed to the
direct, unattenuated Pitch input of the Osc A module to ensure correct semitone intervals.
Select Capture ‘Evenly’ to make the notes be output at a steady rate when controlled from the Triangle
wave LFO.
P
ART
Q
UANT
The Partial Quantizer module is used to transpose an
Oscillator to one of its harmonic partials. It works similar
to the NoteQuant module, but instead of quantizing to
seminote values this module quantizes to ‘overtone’ values. The PartQuant module is similar to the Part
We have selected the notes
E, F and F# to quantize to
in every octave. The Cap-
ture function is set to
’Closest’. As you can see,
the quantization will be to
the closest matching note.
Here the Capture function
is set to ‘Evenly’. As you
can see, the input signal
will be quantized to the se-
lected notes in equal sec-
tions, per octave, across
the selected range.
input values
input values
output notes
output notes
