13. Module reference: Note group NORD MODULAR G2 V1.4x
Page 164
NOTE GROUP
Modules in this group do operations on blue signals that represent keyboard note information. In this
group you will find modules that can rescale and quantize pitch control signals to halfnote scales, chord
scales, harmonic scales and extract pitch control signals from audio signals.
N
OTE
Q
UANT
This module will first scale down the input signal
acoording to the Range setting. Then it will quantize the
scaled input signal to the closest exact semitone which
fits in the semitone scale set by the Notes control.
R
ANGE
KNOB
Scales down a full input signal range between -64 to +64 semitones to the smaller range as shown in the
associated display. If the input range is smaller than full range, e.g. between -32 and +32 semitones, then
the actual output range will be also half of the range shown in the display. Note that one semitone
corresponds to 1 unit in a signal level.
N
OTES
Sets the desired quantization interval in a number of exact semitones. Range: Off and 1 to 127 semitones.
I
N
The blue control signal input.
O
UT
Signal: Bipolar.
K
EY
Q
UANT
This module will first scale down the input signal
acoording to the Range setting. Then it will quantize the
scaled input signal to the closest exact semitone which
fits in the scale set by the mini-keyboard.
R
ANGE
KNOB
Scales down a full input signal range between -64 to +64 semitones to the smaller range as shown in the
associated display. If the input range is smaller than full range, e.g. between -32 and +32 semitones, then
the actual output range will be also half of the range shown in the display. Note that one semitone
corresponds to 1 unit in a signal level.
O
NE
O
CTAVE
M
INI
-K
EYBOARD
B
UTTONS
Click a button on the mini-keyboard to highlight notes that you want to quantize to. The note interval
for the shown octave is automatically duplicated across the whole key Range.
