NORD MODULAR G2 V1.4x 12. midi implementation: G2 MIDI System Exclusive Specification
Page 151
2.2 P
ERFORMANCE
D
UMP
When dumping performances to, or from, the Nord Modular G2 over
MIDI
, each performance will be
split into one or more SysEx blocks. Each of these SysEx blocks has the following format structure:
<name 2> Patch name (2:nd character)
... ...
<name 16> Patch name (16:th character).
If patch name is shorter than 16 characters, it
will be padded with zeros, filling up all 16
name bytes.
$00 Spare
<data 1> Patch data
... ...
<data n> Patch data
<checksum> Least 7 bits of the sum of all bytes sent in this
SysEx block except the checksum itself and the EOX
byte.
$f7 End of System Exclusive
Byte (hex) Description
$f0 Start of System Exclusive
$33 Manufacturer ID (Clavia DMI AB)
<Device ID> Device ID for this specific instrument
Sending a SysEx Performance Dump:
$00...$0f : Corresponds to SysExId = 1 ... 16
$10...$7e : Undefined
$7f : Corresponds to SysExId = 'All'
Receiving a SysEx Performance Dump:
$00...$0f : Corresponds to SysExId = 1 ... 16.
Only the Nord Modular G2 with
specified device ID will respond.
$10...$7e : Undefined
$7f : Corresponds to SysExId = 'All'.
All connected Nord Modular G2's
will respond.
$0a Model ID (Nord Modular G2)
$28 Message ID (Performance Dump)
$00 Nord Modular G2 SysEx protocol version
$00 Spare1
$00 Spare2
<Block ID MSB> ID of this SysEx block (7 most significant bits)
<Block ID LSB> ID of this SysEx block (7 least significant bits)
Block ID (14 bits, MSB and LSB combined) is 0 for
first SysEx block in a transfer and [Block Count - 1]
for last SysEx block in a transfer.
<Block Count MSB> Total number of SysEx blocks for this
transmission (7 most significant bits)
<Block Count LSB> Total number of SysEx blocks for this
transmission (7 least significant bits)
<name 1> Performance name (1:st character)
<name 2> Performance name (2:nd character)
... ...
<name 16> Performance name (16:th character).
If performance name is shorter than 16 characters,
