12. midi implementation: G2 MIDI System Exclusive Specification NORD MODULAR G2 V1.4x
Page 150
2 I
NCOMING
,
AND
O
UTGOING
, S
YS
E
X
MESSAGES
(
FROM
N
ORD
M
ODULAR
G2)
2.1 P
ATCH
D
UMP
When dumping patches to, or from, the Nord Modular G2 over
MIDI
, each patch will be split into one
or more SysEx blocks. Each of these SysEx blocks has the following format structure:
<Device ID> Device ID for this specific instrument
$00...$0f : Only the Nord Modular G2 with
specified device ID will respond
$10...$7e : Undefined
$7f : All connected Nord Modular G2's will
respond
$0a Model ID (Nord Modular G2)
$40 Message ID (All Controllers Request)
<Slot> $00...$03 : Corresponds to slot A to D
$04 : Corresponds to active slot
$05...$7f : Undefined
$f7 End of System Exclusive
Byte (hex) Description
$f0 Start of System Exclusive
$33 Manufacturer ID (Clavia DMI AB)
<Device ID> Device ID for this specific instrument
Sending a SysEx Patch Dump:
$00...$0f : Corresponds to SysExId = 1... 16
$10...$7e : Undefined
$7f : Corresponds to SysExId = 'All'
Receiving a SysEx Patch Dump:
$00...$0f : Corresponds to SysExId = 1 ... 16.
Only the Nord Modular G2 with
specified device ID will respond.
$10...$7e : Undefined
$7f : Corresponds to SysExId = 'All'.
All connected Nord Modular G2's
will respond.
$0a Model ID (Nord Modular G2)
$20 Message ID (Patch Dump)
$00 Nord Modular G2 SysEx protocol version
<slot> Slot from which the patch originates.
If patch was requested from synthesizer file
system, slot equals$04 (=active slot)
$00 Spare
<Block ID MSB> ID of this SysEx block (7 most significant bits)
<Block ID LSB> ID of this SysEx block (7 least significant bits)
Block ID (14 bits, MSB and LSB combined) is 0 for
first SysEx block in a transfer and [Block Count - 1]
for last SysEx block in a transfer.
<Block Count MSB> Total number of SysEx blocks for this
transmission (7 most significant bits)
<Block Count LSB> Total number of SysEx blocks for this
transmission (7 least significant bits)
<name 1> Patch name (1:st character)
