12. midi implementation: G2 MIDI System Exclusive Specification NORD MODULAR G2 V1.4x
Page 148
G2 MIDI SYSTEM EXCLUSIVE SPECIFICATION
The Nord Modular G2 supports
MIDI
S
YS
E
X
dump and download of single Patches and Performances
over the
MIDI
IN
and
MIDI
OUT
connectors on the backside of the G2. With this function you can upload
patches or performances directly from a Nord Modular G2 to a
MIDI
sequencer device or another Nord
Modular G2, or receive patches or performance from another
MIDI
device without having to use the
Editor program.
Note that a
MIDI
S
YS
E
X
dump will have another file format than a ‘.pch2’ patch or ‘.prf2’ performance
file. Only a
MIDI
S
YS
E
X
file that was uploaded to and stored on a computer with the ’Dump One’
command, plus a
MIDI
S
YS
E
X
dumper utility program running on the computer, can be send back to a
G2 system over the
MIDI
IN
connector. The ‘.pch2’ patch or ‘.prf2’ performance files can only be used
by the Editor program.
Refer to “Dump One” on page 29.
The Nord Modular G2 V1.3x supports the following
MIDI
S
YS
E
X
messages:
1 I
NCOMING
S
YS
E
X
MESSAGE
(
TO
N
ORD
M
ODULAR
G2)
1.1 P
ATCH
R
EQUEST
(
PATCH
SPECIFIED
BY
SLOT
)
When receiving the SysEx message specified below the Nord Modular G2 responds by sending the
specified patch over
MIDI
as a S
YS
E
X
dump (see description of SysEx Patch Dumps).
1.2 P
ATCH
R
EQUEST
(
PATCH
SPECIFIED
BY
FILE
INDEX
)
When receiving the SysEx message specified below the Nord Modular G2 responds by sending the
specified patch over
MIDI
as a S
YS
E
X
dump (see description of SysEx Patch Dumps).
Byte (hex) Description
$f0 Start of System Exclusive
$33 Manufacturer ID (Clavia DMI AB)
<Device ID> Device ID for this specific instrument
$00...$0f : Only the Nord Modular G2 with
specified device ID will respond
$10......$7e : Undefined
$7f : All connected Nord Modular G2's will
respond
$0a Model ID (Nord Modular G2)
$30 Message ID (Patch Request by slot)
$<Slot> $$00...$03 : Corresponds to slot A to D
$04 : Corresponds to active slot
$05...$7f : Undefined
$00 Spare, must be$00
$f7 End of System Exclusive
Byte (hex) Description
$f0 Start of System Exclusive
$33 Manufacturer ID (Clavia DMI AB)
<Device ID> Device ID for this specific instrument
$00...$0f : Only the Nord Modular G2 with
specified device ID will respond
$10...$7e : Undefined
$7f : All connected Nord Modular G2's will
