NORD MODULAR G2 V1.4x 9. Editor menu reference: Synth menu
Page 121
MIDI
CHANNEL
Set the
MIDI
channel for each Slot. This channel will be used for reception and transmission of
MIDI
messages.
MIDI
Active check box:
Click in the corresponding check box to activate the Slot to receive and transmit
MIDI
messages.
L
OCAL
O
N
Click the Local On check box to turn the
MIDI
Local Control on. Select Local On to be able to control
the synth from the internal keyboard and the pedals.
MIDI
data is also transmitted via the
MIDI
OUT
jack.
In the Local Off mode, the keyboard and pedal actions are transmitted only via
MIDI
and do not control
the synth itself. Local Off should be used with external sequencers if the
MIDI
OUT
jack of Nord Modular
G2 is routed back, via the external sequencer, to the
MIDI
IN
jack. If Echo is active in the sequencer,
“double notes” will appear when playing the keyboard in Local On mode.
MIDI
S
ETTINGS
G
LOBAL
C
HANNEL
:
Here you set the Global
MIDI
Channel for the synth. The Global
MIDI
Channel should be used for
sending and receiving
MIDI
note data and for sending control data (Modwheel, Aftertouch, Velocity,
Aftertouch and Pedals) as well as sending and receiving
MIDI
Program Change messages in Performance
mode to change to another Performance. Select Global
MIDI
Channel by clicking the arrow buttons.
S
YS
E
X
ID:
Here you can set an ‘Instrument SysEx ID’. This is very useful if you’re sending SysEx dumps of sounds
from a sequencer to the Nord Modular G2 and have several G2 synthesizers
MIDI
connected. Let’s say
you have two G2 synthesizers. These two instrument models have the same ‘Manufacturer ID’ and
‘Model ID’ in the SysEx protocol. By defining separate SysEx ID’s on the two synths, you will be able
to “direct” the SysEx dumps from the sequencer to one of the G2’s while the other one will ignore the
dumps. Just make sure that you define a separate SysEx ID before dumping the sounds to the sequencer.
Select Instrument SysEx ID by clicking on the arrow buttons. If SysEx ID is set to All the G2 will ignore
the SysEx ID in the SysEx data and always accept the SysEx data.
S
END
C
LOCK
:
Here you choose whether or not to send out
MIDI
Clock to the
MIDI
OUT
jack of the synth. Sending out
a
MIDI
Clock signal will only work when you use the internal Master Clock as clock source.
I
GNORE
E
XTERNAL
C
LOCK
:
Here you choose whether or not to accept external
MIDI
Clock signals received on the
MIDI
IN
jack of
the synth. If unchecked, the Master Clock of the synth will automatically sync to any incoming
MIDI
Clock.
C
ONTROLLERS
: R
ECEIVE
AND
S
END
:
Here you select how the synth should handle
MIDI
Controller messages. Select Off, Send and Receive by
clicking in the respective check boxes.
P
ROGRAM
C
HANGE
:
Here you select how the synth should handle Program Change and Bank Select (Controller #32)
MIDI
messages. Select Off, Send and Receive by clicking in the respective check boxes.
T
UNE
M
ASTER
T
UNE
:
Use this function to tune the synth to other instruments. The range is from -6 to +6 semitones and fine
adjustment from -100 to +100 cents. 100 cents is one semitone. All Oscillator modules are affected by
the Master Tune function. Select tuning with the respective arrow buttons.
G
LOBAL
O
CTAVE
S
HIFT
:
