NOTES
Use the new hose assembly that comes with the washing machine. The old hose
assembly cannot be reused.
Connection of water supply hose to faucet
7. To remove the water supply hose, please press
the retaining ring of the water supply hose.
8. To install the water supply hose, please turn the
retaining ring of the water supply hose back to
release it.
Retaining
ring
Make sure that
the retaining ring
Is on the
connector
2. Loosen the four mounting screws on the upper
part of the connector, and rotate the lower part of
the connector to leave a distance enough (equal
to the height of 3 threads) for installing screws
between the upper part and the lower part of the
connector.
If the diameter of the tap tube is too large, remove the
plastic guide inside
1. Hold the connector with one hand, press the
retaining ring with the other hand and pull it down
to separate the connector from the water supply
hose.
4. Hold the upper part of the connector against
the mouth of the faucet so that the seal ring in the
connector is fully in contact with the faucet
(please do not take out the seal ring).
Please choose standard faucet, faucet mouth must
be smooth. If it is uneven, file it.
3. Adjust the four screws of the connector evenly
so that two screws near the wall are fully in contact
with the exterior of the faucet first.
Screw near the wall can be screwed several threads
in advance.
6. Rotate the lower part of the connector to screw
it tightly (or else, water may leak from the
connection). After rotation, the clearance
between the lower part and the upper part of the
connector shall be lower than 3mm.
5. Rotate two screws (see figure) opposite to the
wall so that they are in contact with the faucet, and
screw them with a screwdriver tightly.
connector
Water supply
hose
Retaining
ring
Plastic conduit
The lower part of
connector
The upper part of
connector
wall
Faucet
small
large
connector
Mark for
clearance
Lower than
3mm
Retaining
ring
Retaining ring
