NOTES:

If a special faucet shown in the figure below is used, please take the following steps

to assemble the parts:

1. Replace the

original connector

with the supplied

standard connector.

2. Hold the connector with one

hand, press the retaining ring

with the other hand and pull it

down to separate the

connector from the water

supply hose.

3. Press both sides of the

retaining ring and pull it

down to insert the water

supply hose into the

standard connector directly.

If the faucet with threaded port shown in the figure below is used, please follow the

steps below for installation:

Tap with threaded port

1. Ensure that the gasket in the

water inlet hose connector is

installed smoothly.

2.

Align the water inlet hose

connector with the faucet as

shown in the figure, and tighten the

nut on the water inlet hose in the

direction shown in the installation

figure.

 The washing machine is designed for home use only. Do not use it on ships, travel

9. Check whether or not the lower part of the connector and the water supply hose are connected firmly.

 Screw the connector of the water supply hose and the inlet valve tightly. Slowly turn on the faucet

to check for water leakage.

 If water leaks from the connection, please turn off the faucet and assemble them again. (Water may

leak from the connection if the upper part of the connector is not assembled correctly or the upper

part and the lower part of the connector are not screwed on tightly.)

 After using for a long time, the connection may be loose. Then, please assemble

parts again by

following steps 1-9. (If it is necessary to assemble the connector of the water supply hose after a

move, please follow steps 1-9 too.)

Standard

faucet

Water supply

hose

Standard connector

Water supply

hose

Retaining

ring

Retaining

ring

Retaining

ring

Retaining

ring

Connector

Sealing gasket
