5.2.9 Do not use this fan heater in the immediate surroundings of a bath, a shower or a swimming pool.

5.2.10 If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a

hazard.

5.2.11 Make sure heater is always under surveillance and keep children and animals away from it;

5.2.12 Do not place the appliance on moving vehicles or some where easy to be tipped over.

5.2.13 When you don’t use the appliance for a long time, unplug the appliance. Don’t leave the heater for a considerable amount of time when in use.

Pull the plug straight out, never remove the plug by pulling on the cord.

5.2.14 Keep the heater far from curtain or places where the air inlet can easily be blocked.

5.2.15 The power coupler is waterproof when not in use. In order to prevent possible electric shock or leakage current, never use the appliance with

wet hand or operate the appliance when there is water on the power cord.

5.2.16 Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact you local government for

information regarding the collection systems available.If electrical appliance are disposed of in landfills or dumps, hazardous substances can leak

into the groundwater and get into the food chain, damaging your health and well-being.

5.2.17 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their

safety.

5.2.18 Children should be supervised to ensure that they do not play with the appliance.

6. Using Instructions

6.1 Position the fan heater so that it stands upright on a firm surface and at a safe distance from wet environments and flammable objects.

6.2 Connect the fan heater to the mains.

6.3 Set the thermostat knob to the MAX and let the heater operate with full power.

6.4 The fan heater will switch on when the heating selector is set to one of the power settings.

6.5 Once the room reaches the required temperature, heating element will stop working but fan also working .Once the temperature decreased, the

heating element will be working. The fan heater now starts and stops automatically and thus keeps the room temperature constant.

6.6 Before switch off the heater, please turn the thermostat to MIN position and turn the switch to fan position, let the appliance cool down for two

minutes then turn off the heater and pull out the plug.

6.7 For BGP1505-05-1, BGP1505-05, BGP1505-09, there is an additional thermostat to control the fan motor. If the temperature inside heater is

high, the thermostat will also turn on the fan heater despite that the heater is turned off. For example, after operation, when the heater is turn off, the

fan motor will still operate to cool down the temperature inside.

7. Cleaning and Maintenance

7.1 Before cleaning the appliance,disconnect it from the socket and let it cool down. The enclosure is easily to get dirty, wipe it often with soft sponge.

For every dirty parts, wipe with a sponge dipped in <50°C water and mild detergent, then dry the heater enclosure with clean cloth. Be careful not to

let the water enter the appliance inner. Don’t splash water onto the heater,never use solvent like gasoline etc. to clean the heater,in order to protect

the enclosure.

7.2 Clean the cord and plug,dry and pack it in a plastic bag.

7.3 When you store the heater, let it cool down first, keep it dry. Then cover it with a plastic bag, put in a packing box and store it in a dry, ventilated

place.

8. Trouble shooting:

You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the

problem before calling the service centre.

Problem

Possible cause

Treatment

The heater does not

operate,even when it is plugged

in and the switch, thermostat are

switched on .

The plug is loose, bad connection

Pull out the plug, check the connection of the plug

and socket. Then connect again.

No power in socket outlet Insert the plug in a proper socket

The heating element glowing

The input voltage is too high or too low

Use power supply according to the rating on the

label

The air inlet grill is blocked

Keep the heater far way from articles like curtain,

plastic bag, paper and other things which can

cover the inlet or can be easily cover on the air inlet

The appliance didn’t heat up, or

only ventilator worked

The switch was not put at heating setting

Turn the switch to heat setting

The thermostat operated

Turn the thermostat and listen if there is open/close

voice. If there is no click and the thermostat is not

damaged, the heater will automatic switch on when

the appliance cooled down

The self-resetting cut-out operated

Turn the heater off and inspect the blockage of inlet

or outlet. Disconnect the plug and wait at least

10 minutes for the protection system to reset

before attempting to restart the heater.

Abnormal noise

The appliance is not stands upright

Put the heater on a level surface

Disposal

Environmental Protection

Waste electrical production should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local

Authority or retailer for recycling advice.

Model identifier(s): 90-067

Item

Symbol

Value

Unit

Item

Unit

Heat output

Type of heat input, for electric storage local space heaters only (select one)
