Read carefully-The infrared heater is designed for safe operation. Nevertheless, installation, maintenance and operation of the heater can be

dangerous. Observing the following procedures will reduce the risk of fire, electric shock, injury to person and keep installation time to a minimums.

1.1 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack

of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

1.2 WARNING: In order to avoid overheating, do not cover the heater.

1.3 Children of less than 3 years should be kept away unless continuously supervised.

1.4 Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended

normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the

hazards involved.Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.

1.5 CAUTION-some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable

people are present.

2. Introduction

2.1 Depending on the power cord type this fan heater may be used only in household, warehouses and workshops, building sites or greenhouses

depending. It incorporates a thermostat and a self-resetting thermal cut-out to control the heating elements. The thermostat feels the air temperature

and controls the surrounding temperature. The fan motor is not controlled by thermostat and it keeps on working when the thermostat cuts off the

heating element for BGP1505-05, BGP1505-05-1 and BGP1505-09.The fan motor is controlled by thermostat and it stop working when the thermostat

cuts off the heating element for BGP1505-02 and BGP1505-03. The self-resetting thermal cut-out will switch off the heater to ensure the safety when

overheating. There is an additional thermostat to control the fan motor. If the temperature inside heater is high, the thermostat will also turn on the

fan heater despite that the heater is turned off. For example, after operation, when the heater is turn off, the fan motor will still operate to cool down

the temperature inside.

2.2 When using the heater for the first time, you may notice a slight emission of smoke. This is quite normal and it stops after a short time. The

heating element is made of stainless steel and was coated with protection oil by production. The smoke is caused by the left oil when heated .

3. Technical specifications

Model

90-067

90-068

90-069

Voltage

220-240V~

380-400V 3~

required power

2000W

3000W

5000W

current

8.3-9.1A

12.5-13.6A

7.2-7.6A

Setting

40/2000W

40/1500/3000W

55/2500/5000W

Self-resetting Thermostat

45°C

55°C

55 °C

Product meas (mm)

230x220x290

245x240x310

330x290x360

N.W.(KG)

3.0

3.4

6.5

3.1 Housing of steel plate and coated by heat-resistant powder .

3.2 Supplied complete with cord and plug .

4. Description of Control Panel

90-067

90-068

90-069

4.1 Left Knob: selector with heat setting

the device is turned off

fan on

the heating element works at half power

the heating element is working at full power

4.2 Right Knob: Thermostat dial

5. Special safety regulations

5.1 Before use, please check the marking on the power cord. Depending on the power cord type this appliance may be used in different ambient

conditions:

Type

You can use the appliance in

Do not use in

H07RN-F

household, warehouses and workshops, building sites or greenhouses

H05RN-F

household, warehouses and workshops or greenhouses

building sites

H05RR-F

household, warehouses and workshops

building sites or greenhouses

5.2 When using electrical appliance basic precautions should always be followed including below:

5.2.1 The fan heater is not suitable for use outdoors in damp weather, in bathrooms or in other wet or damp environments.

5.2.2 Please note that the fan heater can become very hot and should, therefore, be placed at a safe distance from flammable objects such as

furniture, curtains and similar.

5.2.3 Do not cover the fan heater.

5.2.4 The fan heater must not be located immediately below a socket outlet.

5.2.5 Do not connect the fan heater using an on/off timer or other equipment which can automatically switch the device on.

5.2.6 The fan heater must not be placed in rooms where flammable liquids or gases are used or stored.

5.2.7 If an extension cord is used, it must be as short as possible and always be fully extended.

5.2.8 You must not connect other appliances to the same mains socket as the fan heater.
