t
44
7.5 ‘TWIG RELAY’ MODULE
Enclosure: Fiberglass reinforced plastic
Enclosure Dimensions: 10.2” x 11.25”x 5.5”
Weight (with no batteries provided): 5.5 lbs
Relays Four 12 VDC latch contacts, 1 amp current capacity
NEMA Rating 4X
Power Options for input: 110VAC (???mA), 12VDC (??? mA)
Connections: SMA Antenna connector
Radio Frequency: 908-922 MHz, 8 channels preselected by the TD200
Radio power slightly less than 1 watt
Address identity: Factory assigned.
7.6 ANTENNA AND ACCESSORIES
Antenna (standard for TD200 and REPEATER 6 dbi mono-pole Omni antenna
Mounting kit for standard 6 dbi U-bolt bracket, ts 1”-1 1/2” diameter pole
Antenna for short range relays: 2dbi di-pole articulating antenna
Antenna connection: SMA small connector
Antenna cable Co-axial cable with end ttings
7.7 APPROVALS, COMPLIANCE
Approvals and compliance are based upon testing that was done with antennas that are supplied
with the product The products within the TD200 system are substantially all manufactured in USA.
These are the approvals to date and other approvals are pending.
7.7a FCC Rules
Contains FCC ID: ZH6-VRCOMM-HP / Contains transmitter module IC: 9686A-VRCOMMHP. All
devices on the system complies with Part 15 Rules. Operation is subject to the following two
conditions: (1)this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. Normal operation
as described by this guide does not require a FCC license by the owner.
7.8 APPROVED ‘D’ CELL BATTERIES FOR TWIG UNITS
Alkaline 1.5 volt ‘D’ cell batteries are acceptable for use. Several factors affect the service life, including
the temperature and storage, depth of discharge cycles, and power voltage demand. The industry
denition of the service life of a battery is the period until it drops to 60% of its rated capacity. The
battery voltage is displayed as bars on the TWIG. Just remember that it is well worth using the highest
quality batteries that are available and plan on replacing them at the beginning of the season.
7.9 TD200 NETWORK/PROGRAM SPECIAL FEATURES
Network setup uses a self-discovery technology. The TD200 network is made when a TWIG is placed
in the setup (RESET) mode. The radios will search for available networks and display on the TWIG the
TD200 numbers that are found. When the number that is wanted is ENTERED the ‘join’ process takes
place within about 20 seconds. The TD200 can support 100 TWIG eld modules and up to 9 repeaters.
If multi-valve modules are used then it is recommended that no more than 200 valves be
controlled by one TD200 controller. It is possible to have as many as 400 valves controlled but not
recommended more than 200 valves be used due to the complexity that may occur.
