848 Airport Road, Walla Walla, Washington 99362 U.S.A.
Tel: +1 509.525.7660 / Fax: +1 509.525.7907
nelsonirrigation.com
43
7.0: Specications and Approvals
The Nelson Irrigation Corporation wireless TWIG valve control and TD200 controller is a radio
network system. Communication is by radio in the 900 mega-Hertz frequency range. The products
used in the system complies with the FCC rules and does not require a radio license. It also has
received Industry Canada approval. The compliance with FCC rules has been established for the
antennas provided by Nelson and those are the only antennas that are authorized to be used for the
wireless TWIG system. Components in the existing product line are listed below.
7.1 TD200 controller
Controller Enclosure: Poly-plastic
Controller Enclosure Dimensions (no antenna): 10.2” x 11.25” x 5.5”
Controller setup for remote antenna: SMA connection for antenna 6 dbi omni
Controller Weight (with antenna): 5.5 lbs
Enclosure NEMA Rating 4X
Power Options and (input current wireless): 110VAC (150mA), 12VDC (350 mA)
Electrical Connections: wire leads and terminal blocks (110 VAC plug if ordered)
7.2 ‘TWIG-1’ module
Enclosure: Fiberglass reinforced plastic
Enclosure Dimensions: 5.63”x6.88”x4.5”
Weight (with two ‘D’cell batteries): 2.94 lbs
NEMA Rating 4X
Connections: 24 inch wire leads for 1 latch solenoid
Radio Frequency: 908-922 MHz, 8 channels preselected by the TD200
Radio power slightly less than 1 watt
Address identity: factory assigned for each unit, rst letter is A
7.3 ‘TWIG-2’ or ‘TWIG-4’ multi-valve module
Enclosure: Fiberglass Reinforced plastic
Enclosure Dimensions: 5.63”x6.88”x4.5”
Weight (with two ‘D’cell batteries): 3.04 lbs
NEMA Rating 4X
Connections: 24 inch wire leads for 2 or 4 latch solenoids
Radio Frequency: 908-922 MHz, 8 channels preselected by the TD200
Radio power slightly less than 1 watt
Address identity: factory assigned for each unit, rst letter B or D
Antenna options: Dual internal antennas or SMA connection for an external
antenna.
7.4 ‘TWIG REPEATER’ module
Enclosure: Fiberglass reinforced plastic
Enclosure Dimensions: 5.63”x6.88”x4.5”
Weight (with no batteries provided): 2.50 lbs
NEMA Rating 4X
Connections: Antenna connection is provided
Radio Frequency: 908-922 MHz, 8 channels preselected by the TD200
Radio power slightly less than 1 watt
Address identity: Factory assigned ID. Starts with the letter ‘E’.
