N 90, INductIoN cooktop, 80 cm, Flex desIgN
V68YYx4c0
• 80 cm Venting Cooktop Induction: space for 4 pots or pans.
Flexibility of cooking zones
• 2x FlexZones: use cookware of any shape or size anywhere within
the 40cm long zone.
• Cooking zone front left: 200 mm, 230 mm, 2.2 KW (max. power 3.7
KW)
• Cooking zone rear left: 200 mm, 230 mm, 2.2 KW (max. power 3.7
KW)
• Cooking zone rear right: 200 mm, 230 mm , 2.2 KW (max power 3.7
KW)
• Cooking zone front right: 200 mm, 230 mm, 2.2 KW (max. power
3.7 KW)
Usage convenience
• Twist Pad Flex® (select your favourite out of 4 colours): directly
control the power with the removable magnetic knob.
• Light Dialog with two coloured display (white/red): see which
cooking zone is heating and which function is in use on the
two-coloured display.
• Favourite Button: directly access favourite functions with a
configurable button (available with connected Home Connect
account).
• 17 power levels for each cooking zone: precisely adapt the heat
with 17 power levels (9 main levels and 8 intermediate levels).
• Switch-off timer: switches off the cooking zone at the end of the
time set (e.g. for boiled eggs).
• Count-down-timer (can be chosen instead of switch-off timer): an
alarm sounds at the end of the time set (e.g. for pasta).
• Sound volume adaptable to personal preference and needs.
Time saving & efficiency
• Power Boost function for all cooking zones: boil water faster with up
to 50% more energy than at the highest standard level.
• Cooking zones will automatically join and separate based on the
shape and size of the cookware placed.
• PowerTransfer: when moving a pot to a different cooking zone,
transfer all previous settings to the new zone at the touch of a
button.
• When moving a pot on the Flex zone, the settings adjust instantly
and the cooking zone adapts to the size of the cookware
• Automatic zone selection: when switched on, the cooktop
automatically selects the cooking zone on which a new cookware is
placed.
• QuickStart - Quick and automatic first pot detection: when
switching on, the cooktop automatically selects the cooking zone
with cookware on it.
• ReStart function: in case of unintentional switch-off, restore all
previous settings by switching on the cooktop again within 4
seconds.
Cooking assistance
• Frying Sensor Plus sensor: choose from 11 predefined temperatures
in a range from 70°C up to 220°C for perfect results every time.
• Dish assistant: easily find the right temperature setting for a certain
dish via the Home Connect app.
Connectivity
• Remote Monitoring and Control: check if the cooktop is switched off
even when not at home, and find recipes or additional functions in
the Home Connect app.
• Smart home trigger, via Favourite button (available with connected
Home Connect account): open up the smart universe from your
cooktop (partner service required).
• Updateable appliance (available with connected Home Connect
account): easily keep your appliance up to date with the latest
software.
Design
• Flex Design: exchangeable side trims (select your favourite out of 4
colours)
• Neff Collection exclusive zone printing: minimalistic design thanks
to dark coloured zone printing.
Safety
• Residual heat indicator: Digital 2-step: indicates which cooking
zones are still hot or warm.
• Child safety lock: prevent unintended activation of the cooktop.
• Main switch: switch off all cooking zones at the touch of a button.
• Automatic safety switch-off: for safety reasons, heating stops after
a preset time without interaction.
Installation
• Dimensions of the product (HxWxD mm): 223 x 834 x 527
• Required niche size for installation (HxWxD mm) : 223 x 750 x (490
- 500)
• Min. worktop thickness: 16 mm
• Connected load: 7.4 KW
• Power cord: 1.1 m, Cable included
Accessories
• Clean Air Plus odor filter, Slider for unducted recirculation included
Integrated ventilation downdraft system
• Induction cooktop with fully integrated high-performance
downdraft extractor.
• Aesthetically integrated fully flush air intake design with floating,
heat resistant glass ceramics element for free movement and
placement of cookware.
• Ventilation system with 17 electronically controlled fan power levels
and 2 Boost-/Intensive fan power levels (with automatic revert) via
Twist Pad Flex® (select your favourite out of 4 colours) user
interface.
• Automatic switch-on of ventilation system when a cooking zone is
used.
• Sensor-based and cooktop-based, fully-automatic adjustment of
power levels via advanced algorithm for maximum convenience.
• 3 possible sensitivity modes of algorithm for maximum convenience
(Low-noise oriented, balanced, performance-oriented).
• Automatic delayed shut-off after cooking to erase residual odors
after cooking (in specific ultra low-noise fan level, 12min in ducted
extraction, 30min in recirculated extraction, can be shut-off
manually).
• High-performance, low-noise blower with energy-effcienct
BLDC-technology. High extraction rates at very low noises with
pleasant noise frequencies through psycho-acoustically and
3 /
