Installation instructions en
brackets engage. Avoid impacts and putting pressure
on one side when doing so.
2.
Tighten the two fastening screws alternating between
the left and right. Use a suitable tool to avoid dam-
aging the surface.
3.
Screw in the front two screws and select a hole so
that the surface of the appliance is flush with the fitted
unit.
4.
Insert the two screw covers.
Establishing the exhaust air connection
1.
Secure the air pipe to the air pipe connector.
2.
Establish the connection to the exhaust air opening.
3.
Seal the joints.
Removing the appliance
WARNING‒Risk of injury!
Components inside the appliance may have sharp
edges.
Wear protective gloves.
1.
Disconnect the appliance from the power supply.
2.
Loosen the exhaust pipe.
3.
Open the filter cover.
4.
Remove the grease filters.
To avoid causing damage, do not bend the grease fil-
ters.
5.
Loosen the two front screws
6.
Loosen the two fastening screws on the brackets al-
ternating between the left and right.
7.
Slowly take the appliance down.
13
