en Installation instructions
Notes
If a one-way flap is not included with the appliance,
one can be ordered from a specialist retailer.
If the exhaust air is conveyed through the external
wall, a telescopic duct should be used.
13.10 Information about circulating-air mode
The appliance must only be operated when it is securely
installed and the pipework is connected.
13.11 Installation
Checking the unit
1.
Check whether the fitted unit is level and has suffi-
cient load-bearing capacity.
The maximum weight of the appliance is 10kg.
Note: Note the furniture manufacturer's specifications
with regard to the load-bearing capacity of the fitted
unit.
2.
Ensure that the fitted unit is heat-resistant up to
90°C.
3.
Ensure that the fitted unit is still stable after the cut-
outs have been made.
4.
Check the door hinges setting.
Depending on the design of the furniture, these may
no longer be accessible after installation.
Preparing the units
Requirement: The unit is suitable for the installation.
1.
Make the cut-out for the appliance.
When doing so, make sure that the permissible di-
mensions are complied with.
2.
Make the cut-out for the exhaust air pipe either above
the fitted unit or behind the fitted unit above the appli-
ance.
Unpacking the appliance
Unpack your appliance and check all parts for any
transport damage. Wear protective gloves when you un-
pack the appliance.
ATTENTION
The appliance frame is not a hand grip element.
Do not lift the appliance by the frame.
Preparing the appliance
1.
If air extraction is required, fit the backflow flaps on
the air outlet and click them into place.
1
2.
Carefully remove the protective foil from the surface.
Installing the appliance
Note: We recommend that installation is carried out by
two persons.
1.
Insert the appliance together with the power cord into
the opening in the unit from below until you hear the
1
Depending on the appliance specifications
12
