ENG-8
ENG-9
Setup Procedure
Setup Flow
1. Connect the USB cable and the holder to the camera unit.
2. Fix the camera unit onto the projector.
* Fixing procedure for U321H is differed from for other models.
3. Mount the cover on the holder.
4. Connect the projector with the computer.
5. Power on the projector and adjust the position and focus for projected im-
age.
6. Connect the USB cable on which terminal has connected with the camera unit
with the computer.
7. Install the driver and the calibration software on the computer and perform the
calibration.
Warning
- Set up this product on the projector before installing the projector on the ceiling or wall. If
this product is set up after installing the projector on the ceiling or wall, the camera unit may
not be fixed properly and it may cause of falling down and resulting in injury. At the same
time, it may cause of damage on the camera unit.
- Make sure to fasten the screws after fixing on the camera unit. If the screws are not fastened
securely, the camera unit may fall down and result in injury. At the same time, it may cause
of damage on the camera unit.
- Do not hold the camera unit for moving the projector and do not apply excessive force to
the camera unit. It may cause of damage on the camera unit and resulting in injury.
Preparation:
- Prepare a plus headed screw driver
- However the holder and the cover has been in engaged condition for shipment, remove the holder
by pressing the button on the cover.
1
2
For fixing on U321H, you need to seal the gasket on
the holder. Peel off the release paper on the rear face
of the gasket, attach it to the arrow pointed position on
the illustration.
align corners
