English - 10
Installation Example
Before the installation, be sure to review the following safety precautions to ensure proper and safe
installation.
CAUTION
• Ask a technician to perform the installation.
• Make sure the product is moved and installed by enough people to ensure safety.
• Make sure that the beams or the other structures to which the product is installed have enough strength to
support the weight of the product, and make sure that the product is securely xed.
• Do not install directly the product to a surface that has not enough strength.
• When installing the product in a narrow place (in a wall, etc.), leave gaps around the LED screens as shown
in the gure below to prevent an increase in the temperature. The gure below is only an example.
Pay particular attention to the installation environment (heat from the external environment, direct sunlight,
heat generated by the number of displays) in order to facilitate cooling of the LED modules. If cooling is not
sufcient, take measures, such as increasing the distance from the walls or installing a forced-air cooling
system.
Ask a technician or your retailer for more details.
• The power cords, LAN cables, and installation materials (hanging bars, etc.) are sold separately.
1-1. Front installation example
Frame
100 mm or more
50 mm or more
100 mm or more
50 mm or more 50 mm or more
Wall
Wall
