• Empty and rinse the dirty water tank
• Discard the self-contained waste separation bag—pull
the handle out along the slide groove
• If the self-contained waste separation bag is not installed,
empty the solid waste box.
• Rinse the solid waste box and the filter slot
Dirty water tank module/Self-contained waste separation bag
• Remove the dirty water tank, filter, and solid waste box
in order
Maintenance Methods
Pull out the filter from the top of the solid waste box.
Pull out the waste box in the direction of the arrow.
Dirty water tank
Self-contained waste separation bag
Filter 2.0
Integrated deodorant module
Roller brush cover
Soft Velvet Roller Brush
Pipe
Clean regularly on demand
Discard as necessary
Clean regularly as needed and replace every 3-6 months
Replace every 1-3 months based on actual usage
Clean regularly on demand
Clean regularly as needed and replace every 9-12 months
The vacuum can intelligently detect the roller brush wearing
and reminds the user to replace it timely
Clean regularly as needed
Cleaning and Maintenance
Suggested Maintenance Cycle
Main Part
Wet Dry
Vacuum
Part Suggested maintenance cycle
Press the dirty water tank
release buon to remove
the dirty water tank.
Roller brush cover
•Slightly press the roller brush release buon to remove
and rinse the roller brush cover
Soft Velvet Roller Brush
•Grab the tab on the right and pull it out gently, and then
clean the roller brush
Pipe
•If the machine prompts a high dirt level when the floor is
free from obvious dirt and several rounds of self-cleaning
have been completed, the pipe may be dirty;
•The vacuum mop prompts that the pipe gets clogged.
(Use the cleaning brush to clean the pipe for the above two
situations)
1. Push down to open it
2. Pull it up
2. Stick the brush inside to
clean the interior of the pipe
1. Clean the dirt suction port.
DO NOT rinse it
Filter 2.0
•Clean up the filter with clean water. You can open the
filter cover. Shake dry the filter and then put it back into
the machine for filter drying
You can open it to clean
Vacuum mop and self-cleaning base
•To ensure optimal performance, you are recommended to maintain all parts regularly;
•Before cleaning any part, please turn o the machine and unplug the power cord;
•Use a clean and dry cloth to scrub clean the machine and the base and prevent water ingress into electrical components.
Do not rinse with water
In case of any fault when the product is working (no action or fault prompt on the screen or via voice), please refer to
the following table:
Problem Analysis and Troubleshooting
FAQ
The vacuum voice prompts "Filter of the dirty water tank not
in place. Please install it and check the dirty water tank"
The vacuum voice prompts "Roller brush not in place" Check whether the roller brush is properly installed
Description
Possible Causes and Solutions
The vacuum voice prompts "Roller brush stuck. Please
clean it"
Manually clean the pipe and roller brush
Check whether the dirty water tank is installed properly
05
