How to fill the clean water tank
1. Take out the clean water tank
Pull out the clean water tank to take it out.
3. Add detergent
• Slightly press the right buon to pull up the roller brush
cover.
•Pour the detergent, filling it to the MAX line. A full dispenser
can last around 40 days.
Note: There detergent has a sealing film. Please unscrew the cap
and remove it.
Please use the detergent from Narwal, otherwise, the device
may be damaged.
•Please check the see-through window and add detergent
as needed when the color changes from orange to white.
Note: When the detergent is added, the window will only change
to orange when the vacuum works for a period of time (15-120s).
This is normal and the product performance remains unaected.
•Open the detergent dispenser.
2. Add clean water
Open the sealing cover and fill water from the tank opening.
Clean water tank latch
After the self-cleaning base is connected to a power supply, put the vacuum
mop on the base. When it rings ding-dong, the screen shows the charging
animation, and charging starts.
How to remove: Please use a hard object
to insert into the hole on the side of the
machine and keep pressing while pulling
up the handle to remove it.
Insert vertically; after hearing a “click,” ensure that
the handle is tight and secure.
How to Use
First-time Use
How to install the handle
How to charge the product
2. Pinch the clip to slightly open it and remove the
integrated deodorant module.
Installation of integrated deodorant module
1. The release hole of the integrated deodorant module
should face outward, matching the shape of the boom
of the solid waste box. Then press it in.
The three clips of the integrated deodorant module should snap
into the corresponding notches at the boom of the solid waste
box for proper installation.
Gently press the handle to pull it
Unlock
Lock
(Unlocked when the angle is <90°)
How to unlock and start the machine
Remove the washer from the self-cleaning base. Short
press the Power On/O buon and then follow the voice
prompts to slightly press and recline the lever to start
cleaning. You can also recline the lever and then short press
the Power On/O buon to use the washer.
Unlock and Start
In addition to the built-in solid waste box, a self-contained waste separation bag can be installed for easy disposal of solid waste.
Installation of self-contained waste separation bag
•1. Open the self-contained waste separation bag support
plate and handle, pressing down at an angle exceeding 90°.
2. Insert along the slide groove. 3. Snap the upper edges
on both sides.
2
1
3
• Hold the handle when removing it along the slide groove.
On the initial startup, a language switch
reminder page will appear. Press the
Mode buon and Self-cleaning buon
simultaneously to change the system
language.
Click
Language Switch Instructions
Click
03
