WWW.NANLITE.COM
PavoTube II 6XR 8KIT
10
5.1.2. Battery Level Instructions
The PavoTube II 6XR has 8 pixels in total, in the 8-light kit case, each pixel represents 12.5% of the battery level. If the
PavoTube II 6XR shows yellow light, it indicates that the battery level is ≤ 37.5%. If the PavoTube II 6XR shows green
light, it indicates that the battery level is > 37.5%.
When the PavoTube II 6XR shows 1 pixel with a breathing effect, it indicates that the battery level is between 0% and
12.5%.
When the PavoTube II 6XR shows 2 pixels with a breathing effect, it indicates that the battery level is between 12.5%
and 25.0%.
When the PavoTube II 6XR shows 3 pixels with a breathing effect, it indicates that the battery level is between 25.0%
and 37.5%.
When the PavoTube II 6XR shows 4 pixels with a breathing effect, it indicates that the battery level is between 37.5%
and 50.0%.
When the PavoTube II 6XR shows 5 pixels with a breathing effect, it indicates that the battery level is between 50.0%
and 62.5%.
When the PavoTube II 6XR shows 6 pixels with a breathing effect, it indicates that the battery level is between 62.5%
and 75.0%.
When the PavoTube II 6XR shows 7 pixels with a breathing effect, it indicates that the battery level is between 75.0%
and 87.5%.
When the PavoTube II 6XR shows 8 pixels with a breathing effect, it indicates that the battery level is between 87.5%
and 100.0%.
When the PavoTube II 6XR shows 8 pixels as green light and remains steady, it indicates that the battery is fully
charged.
5.2. Firmware Update
Connecting with power source, put the firmware files of the 8-light kit case into the root directory of the USB drive
(ensure the versions of the firmware files are the same), and insert the USB drive to the USB-C port.
Long press the Battery Indicator button, and turn on the power switch at the same time. Continue pressing the button
for 1s to start update.
A flashing indicator light means "searching for firmware", a steady indicator light means "updating", and a breathing
effect on the indicator light means 'updated'
▲Note: ① Please do not rename the firmware files.
② Ensure the USB drive is formatted to FAT, FAT32 or exFAT.
③ If the indicator light keeps flashing for 10s and no firmware is found, the 8-light kit case will stop updating
and power on. In this situation, please check whether the firmware files are correct, whether they are stored in the root
