IP Camera
Video Compression
Video Stream
Main Stream Resolution
Sub Stream Resolution
Bit Rate Control
frame rate
Audio Compression
Supported protocols
H.264
First and second streaming
1920x1080, 1280x720, 1024x576, 960x540, 640x480, 640x360
1280x720, 1024x576, 720x576, 720x480, 720x408, 640x360, 480x270,
320x240, 320x180
VBR, CBR
1fps ~ 60fps
AAC
96Kbps, 128Kbps, 256Kbps
FULL NDI, NDI｜HX, TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast, SRT,
GB/T28281
Video Bit Rate
32Kbps ~ 102400Kbps
Audio Bit Rate
Input/Output Interface
12VDC，PoE（802.3af）
Order Information 500791-NDI USB/NDI/IP PTZ Camera 12x Zoom, PoE (UPC: 627699027912)
1 x RJ45:10M/100M/1000M Adaptive Ethernet, supported PoE
HD Output
Network Interface
1 x 3G-SDI: BNC type, 800mVp-p, 75Ω, Comply with SMPTE 424M standard
Audio interface
1 x Line In, 3.5mm Jack
Generic Specification
1 x RS232 Out: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA only
1 x RS485: 2pin phoenix port, Max Distance: 1200m, VISCA/Pelco-D/Pelco-P
Power Jack
JEITA Type（Input 12VDC）
Input Voltage
Input Current
1.5A (Max)
Operating Temperature 0°C ~ 40°C
Storage Temperature -10°C ~ 50°C
Power Consumption
15W
Size
169mm x 142mm x 175mm
Net Weight
1.5Kg
Warranty
2 years
USB 1-ch, USB 3.0: Type-A
1 x HDMI: V 1.3
1 x Line Out, 3.5mm Jack
Control Interface
1 x RS232 In: 8pin Min DIN, Max Distance: 30m, VISCA/Pelco-D/Pelco-P
© MuxLab Inc. 2024 6 94-001062-A/SE-001062-A
USB/NDI/IP PTZ Camera 12X Zoom, PoE
