Rev. 01.07.2024
Rev. 01.07.2024
These hazards can occur both during normal machine
operation and as a result of irregularities in machine
operation. These irregularities might result in machine
failure. The mechanical hazards can result from: moving
machines, transported loads, moving elements, sharp/
rough elements, dropping elements/loads, slippery uneven
surfaces, limited space, location of the work station in
relation to the ground.
3.6. CLEANING AND MAINTENANCE
a) Before each cleaning, adjustment, exchange of
accessories and when the device is not in use,
disconnect the mains plug and the compressed air
supply line, equalize the pressure in the cylinders
with atmospheric pressure and completely cool the
device.
b) Use only non-corrosive cleaners to clean the surface.
c) After cleaning the device, all parts should be dried
completely before using it again.
d) Store the unit in a dry, cool place, free from moisture
and direct exposure to sunlight.
e) Before putting the machine into storage, lubricate
all coupled moving parts, empty the oil / liquid
container and cover the machine with a plastic tarp
to prevent dust settling on it.
f) Never spray the device with water.
g) Do not allow water to get inside the device through
vents in the housing of the device.
h) Clean the vents with a brush and compressed air.
i) The device must be regularly inspected to check its
technical eciency and spot any damage.
j) Use a soft cloth for cleaning.
k) Movable parts should be regularly lubricated
depending on how often they are used. It is
recommended to do this once a week.
l) Regularly check and correct the drive belt tension.
m) Regularly check the connections of all parts and
tighten the loose nuts and bolts.
n) Regularly check and remove sediment,
contamination and water from the compressed air
unit of the machine.
Inspections and periodic control
Before being used, the new or repaired machine must
be checked by qualied technical personnel who have
knowledge and experience within the scope of operation
and maintenance of this type of machine. The machine
must be checked regularly by means of visual control of
the machine’s condition, before, during and after use. The
check must be performed by the machine’s operators. Any
irregularities in machine operation as well as any damage
must be reported to the proper technical personnel. Do
not use the machine if damage or any irregularities in its
operation were found.
IMPORTANT: Before each inspection, disconnect the
machine from the power and compressed air supply. After
disconnecting the power supply, use the separator 3-4
times to get rid of the pressure in the machine's pneumatic
system.
Machine inspection every 30 days:
• Check the oil level in the lubricating tank. The
recommended oil is SAE30.
• Check that there is oil in the tank (1).One drop of oil
should be added every 3-4 clicks of the separator
control pedal. If it is not, adjust with the screw (2) as
shown in the drawing below.
• Tighten the jaw screws and screws under the
turntable.
• If the turntable does not work, the drive belt may be
too loose. Adjust the drive belt.
• Adjust the locking lever screw [10] (applies to MSW-
TC-750) to allow the mounting arm to be locked.
• If the clamping jaws or the separator move too
slowly, clean or replace the suppressor.
2
1
19
EN
