Rev. 01.07.2024
m) Do not move, adjust or rotate the device in the
course of work.
n) Do not use the machine with more than one wheel at
a time.
o) Only use air to supply the device, do not use any
other gases.
p) Clean the device regularly to prevent stubborn grime
from accumulating.
q) At locations where there is a high risk of mechanical
damage, use a reinforced hose for compressed air
connections.
r) Before each use ensure the nozzle is correctly
installed in the device and that the hose is correctly
attached and undamaged.
s) The air supplied to the device should be dry, clean
and free of contamination. Contamination can clog
the conduits and lead to damage to the device and
its components.
t) Do not exceed the recommended supply pressure as
this may damage the device.
u) Do not cover the air intake and outlet.
v) The machine may only be used by trained persons
who understand its operation and safety rules.
w) Do not stand near the machine while it is running.
x) Unauthorized persons should keep a safe distance
from the working machine.
y) Do not leave unattached nuts, bolts, tools or other
objects on the machine as they may get between the
moving parts while the machine is in operation.
ATTENTION! Despite the safe design of the device
and its protective features, and despite the use of
additional elements protecting the operator, there is
still a slight risk of accident or injury when using the
device. Stay alert and use common sense when using
the device.
3. USE GUIDELINES
The device is designed for demounting and mounting tyres
on passenger car wheels.
The user is liable for any damage resulting from
unintended use of the device.
3.1. DEVICE DESCRIPTION
1. Separator control pedal
2. Jaws control pedal
3. Turntable rotation control pedal
4. Clamping jaws
5. Turntable
6. Mounting head
7. Mounting arm
8. Knob limiting the movement of mounting arm
9. Swivel arm
10. Locking lever
11. Ination gun with pressure gauge
12. Column
13. Accessories / grease container
14. Separator arm
15. Separator blade
16. Stopper
17. Tyre lever
18. Three-tool support
19. Tyre bead clamp
20. Circular roller
ATTENTION! This product‘s view can be found on
the last pages of the operating instructions (pp. 64).
Operation of control pedals:
1. Press the pedal to start the tyre separator. After
releasing the pedal, the separator returns to its
starting position.
2. Press the pedal to open the four jaws of the device.
Press again to close the jaws.
3. When the pedal is pressed, the turntable will rotate
clockwise. When the pedal is released, the turntable
will rotate counter-clockwise. 22 (only model MSW-
TC-1100HA) – Pressing the pedal causes the column
to tilt backwards. Pressing the pedal again causes the
column to return to its initial position.
The compressed air gun trigger can be in 3 positions:
• trigger in its initial position (not pressed) – the air
ow is closed
• trigger partially depressed – air is let out
• trigger pressed all the way – air is pumped in
3.2. PREPARING FOR USE
Unpacking
Use gloves when unpacking the machine. After unpacking,
check that it is in good condition and that all parts have
been delivered and are not damaged. If in doubt as to the
eciency and completeness of the machine, contact the
manufacturer. The packaging and its components (nails,
plastic bags, clamps, lms, pieces of wood) should be kept
(for transport or storage of the machine) in a safe place
away from children.
APPLIANCE LOCATION
The following conditions should apply in the workplace:
21. Locking switch
22. Column control pedal
23. Pressure roller
24. Three-tool support control switch
25. Security tip
26. Machine body
Ambient temperature [° C] (-20)-45
Humidity [%] 30-95
Maximum height above sea
level [m]
1000
Ensure good ventilation in the room in which the device is
being used. There should be at least 10 cm distance between
each side of the device and the wall or other objects. Keep
the device away from hot surfaces. Operate the device on an
even, stable, clean, re-proof and dry surface and out of the
reach of children and persons with mental disabilities. The
machine should be positioned in such a way that at any time
you can reach the mains plug and the valve that switches o
the compressed air supply. Make sure that the air pressure
and power supply requirements correspond to the data
provided on the nameplate!
The device should be placed in such a way that the free
space around is not smaller than in the drawing.
