EN
TWO-STEP CUT
Bow – a
djust angle right and left to the required
angle. The supplied angular stop is required for this
purpose. Lift bow in order to draw the material
to be cut underneath the cutting wire up to the
beginning of the cut. Press pushbutton and keep it
pressed (cutting wire heats up). Pull bow in material
direction – bevel will be cut. Release pushbutton.
BEVEL
Bow – adjust angle right and left to 0 degree. Mark
required cut on the polystyrene sheet. Lift bow in
order to draw the material to be cut underneath the
cutting wire. Adjust material in such a way that the
required cut will exactly go along underneath the
cutting wire. Press pushbutton and keep it pressed
(cutting wire heats up). Pull the bow in material
direction – material will be cut. Release pushbutton.
CONCAVE CUT
Bow – adjust angle right and left to 0 degree. Mark
required hollow groove on the polystyrene sheet. Lift
bow in order to draw the material to be cut
underneath the cutting wire up to the marked place.
Press pushbutton and keep it pressed (cutting wire
heats up). Pull bow in material direction – step depth
will be cut. When reaching the step depth pull the
material to the right towards the marked place until
the step length has been cut. Pull the bow upwards
out of the material. Release pushbutton.
MAINTENANCE
Cleaning
a) Pull the mains plug and let the unit cool down completely before cleaning, adjusting or replacing accessories
and when the unit is not in use.
b) Pull out the mains plug before each cleaning and when the unit is not in use.
c) Use only non-corrosive cleaning agents for cleaning the surfaces.
d) After each cleaning, all the parts should be dried well before the unit is used
e) again.
f) Store the unit in a dry and cool place protected from moisture and direct sunlight.
g) Do not spray the unit with a stream of water or immerse it in water. Make sure that no water enters through
the ventilation openings in the casing.
h) Clean the ventilation openings with a brush and compressed air (not exceeding 3 bar).
i) Perform regular inspections of the unit checking technical fitness and any damages.
j) Use a soft, damp cloth for cleaning the device.
k) Do not clean the unit with acidic substances, medical products, diluent, fuel, oil or other chemicals as this may
cause damage to the unit.
l) Clean the blades build up with accumulated material with help of the (included) wire brush.
Disposal
Do not dispose of this device in municipal waste systems. Hand it over to an electric and electrical device recycling
and collection point. Check the symbol on the product, instruction manual and packaging. The plastics used to
construct the device can be recycled in accordance with their markings. By choosing to recycle you are making a
significant contribution to the protection of our environment.
Contact local authorities for information on your local recycling facility.
