Je bekijkt pagina 8 van 22
EN
Drive Belt:
The tension of the drive belt is adjustable. To adjust, loosen the four nuts securing the motor to the
baseplate. Then, adjust the set screws that bear against the motor crankcase to achieve the desired
belt tension. After adjustment, ensure the four nuts and the set screw locknuts are properly tightened.
Accessories
Transport Trolley:
Facilitates easy handling by hooking into the baseplate. It is fitted with 200 mm rubber tyres for
smooth transportation.
3.2. Preparing for use
NOTICE!
Proper moisture content in the soil is essential for effective compaction. Water acts as a lubricant,
helping soil particles bind together. Insufficient moisture leads to inadequate compaction, while
excessive moisture creates water-filled voids that weaken the soil’s load-bearing capacity.
Use unleaded petrol and ensure the fuel is free from contamination.
Position yourself at the handle end of the machine, keeping the vibrator at the opposite end.
Start the engine using the recoil starter. If equipped with an ON/OFF switch, ensure it is turned ON
before starting.
Increase the engine speed to maximum using the throttle lever before beginning compaction.
Firmly grasp the handle with both hands to control the forward motion.
Steer the machine by moving the handle sideways to the right or left.
Maintain stable footing to avoid slipping and losing control while starting or operating the machine.
BEFORE USE
1. Thoroughly remove all dirt, mud, and debris from the unit before operation. Pay special attention to
the bottom face of the vibrating plate and the areas near the engine cooling air inlet, carburetor,
and air cleaner.
2. Check all bolts and screws to ensure they are securely tightened. Loose bolts and screws may cause
damage to the unit.
3. Inspect the V-belt for proper tension. The normal slack should be approximately 10-15mm (1/2")
when pressed at the midpoint between the two sheaves.
Excessive belt play may result in reduced impact force or erratic vibration, leading to machine
damage.
4. Check the engine oil level. If the level is low, refill with the recommended motor oil (refer to the
table and Fig-1 below).
Season & Temperature Recommended Oil Grade
Spring, Summer, or Autumn
(+40°F to +120°F)
SAE 30
Winter
(+15°F to +40°F)
SAE 20
Extreme Cold Weather
(Below +15°F)
SAE 10W-30
