Je bekijkt pagina 6 van 9
06
support@m4sol.com | www.m4sol.com
MS-63U1C USER GUIDE
RS-232 Control
The MS-63U1C can distribute bi-directional serial commands between the transmitter and receiver
to allow for control commands to be sent alongside USB.
Each unit is fitted with a 3-pin phoenix connector block that will need the serial TX, RX and Ground
pins terminating into for serial pass-through. The link has the ability to transparently send any type
of serial data as both pieces of equipment are able to communicate using the same baud rate, stop-
gap, and parity.
USB
This USB 3.2 extender allows for USB-C peripherals including cameras, touch screens, smart
boards, hard drives, games controllers, USB audio devices, printers, scanners, and HID’s (mouse or
keyboard) to be distributed over a distance of up to 100m to a USB-C host device on the far side of
the link.
The extender supports transparent true plug and play USB pass-through without the requirement of
software or driver son the extender kit.
A maximum combined data transfer of 5Gbps can be achieved over the link.
The Micro-USB connections on both Host and Device units are utilised for firmware updating and
are reserved for future CloudOS control.
Note: the USB-C connectivity does not support high-bandwidth video data from a laptop / tablet to
a display due to the limitation of available bandwidth.
Power
The MS-63U1C uses bi-directional PoC (Power over Cable) to provide power from either the Host or
Device unit to the far side of the link over the Cat6A (or above) cable. Please only use the supplied
12V/2A DC PSU supplied with the MSolutions MS-63U1C to power the unit.
