05
support@m4sol.com | www.m4sol.com
MS-63U1C USER GUIDE
Understanding the LED’s
This MSolutions extender set includes status LED indicators on both the Host and Device products
to show active connections and to further help integrators diagnose potential problems with the
associated cabling.
The RJ45 Link connections on both the host and device units have orange and green LED’s.
• The orange LED indicates that the unit is receiving power. The LED will blink continuously when
there is a link to the unit on the opposing side of the cable.
• The green LED indicates that the unit is communicating with the unit attached to the far side of
the link over the Cat cable.
Category Cabling for Extenders
It is important that the interconnecting category cable between the MSolutions products is
terminated using the correct RJ45 pin configuration. The link category cable must be a ‘straight’
(pin-to-pin) category cable and it is advised that this is wired to the T568B wiring standard as this
format is less prone to EMI (Electro-Magnetic Interference).
When installing category cables it is advised that the best possible category cable quality possible
is used. MSolutions recommends using a Cat6A (or above) cable for installations, especially when
running over longer distances, in areas of high EMI, or with high data rate signal distribution.
