<變數 1> 目錄

目�

安全說明...........................................................................................................2

規格 .................................................................................................................. 3

背板 I/O ............................................................................................................6

B365M PRO-VH/ B365M PLUS............................................................................6

B365M PRO-VD ...................................................................................................6

B365M WIND .......................................................................................................6

網路連接埠 LED 燈狀態表 ...................................................................................7

元件總覽...........................................................................................................7

CPU 腳座 .............................................................................................................8

記憶體插槽 ..........................................................................................................9

PCI_E1~3: PCIe 擴充插槽 ...................................................................................9

JFP1, JFP2: 系統面板接頭 ................................................................................10

SATA1~6: SATA 6Gb/s 插孔 ...............................................................................10

M2_1: M.2 插槽 (M 鍵) (B365M PRO-VD, B365M PRO-VH, B365M PLUS) ......11

ATX_PWR1, CPU_PWR1: 電源接頭 ...................................................................11

JUSB1, JUSB2: USB 2.0 接頭 ...........................................................................12

JUSB3: USB 3.1 Gen1 接頭 ...............................................................................12

JAUD1:前置音效插孔 ........................................................................................13

JCOM1: 序列埠接頭 ..........................................................................................13

JTPM1: TPM 模組接頭 ......................................................................................13

除錯 LED 指示燈 ...............................................................................................13

CPU_FAN1, SYS_FAN1: 風扇電源接頭 .............................................................14

JCI1: 機殼開啟接頭 ...........................................................................................15

JBAT1: 清除 CMOS (重置 BIOS) 功能跳線 ........................................................15

BIOS 設定 .......................................................................................................16

進入 BIOS 設定 ..................................................................................................16

重設 BIOS ..........................................................................................................17

更新 BIOS ..........................................................................................................17

安裝操作系統、驅動程式和公用程式 .............................................................18

安裝 Windows

®

10 .............................................................................................18

安裝驅動程式 ....................................................................................................18

安裝公用程式 ....................................................................................................18

感謝您購買 MSI

®

B365M PRO-VD/ B365M PRO-VH/ B365M

WIND/ B365M PLUS 主機板。本用戶指南提供有關電路板佈

局，元 件 總 覽，BIOS 設置和軟體安裝的信息。
