组件概述 组件概述

JAUD1: 前置音频接口

󴦞󳰛󱿂󱭩󸚞󳜂󸴗󳰛󱴚󶷉󹪸󴋃󱘔󹮪󹲙󳱥󲵑

1

2 10

9

1 MIC L 2 Ground

3 MIC R 4 NC

5 Head Phone R 6 MIC Detection

7 SENSE_SEND 8 No Pin

9 Head Phone L 10 Head Phone Detection

JCOM1: 串行端头接口

󴦝󳰚󱿂󱭩󸚞󳜁󸴗󳰚󱿔󸶆󱙏󸀅󶔏󱿂󱿔󵫞󳱤󴜖

1

2 10

9

1 DCD 2 SIN

3 SOUT 4 DTR

5 Ground 6 DSR

7 RTS 8 CTS

9 RI 10 No Pin

简易侦错 LED 灯

LED 󳬙󶆻󵉉󲔩󱙛󴋃󱙆󵵙󵚱󳗷

CPU - 󸀮󶆻 CPU 󴀞󴰢󴓍󴳖󳦕󳼇󹤜

DRAM - 󸀮󶆻 DRAM 󴀞󴰢󴓍󴳖󳦕󳼇󹤜

VGA - 󸀮󶆻 GPU 󴀞󴰢󴓍󴳖󳦕󳼇󹤜

BOOT - 󸀮󶆻󲀹󱶴󸚤󲠫󴀞󴰢󴓍󴳖󳦕󳼇󹤜

JTPM1: TPM 模组接口

󴦝󳰛󱿂󴂞󵫞󴊜󸴗󳰛 TPM (󲶿󾇄󳌣󱿖󴝙󶳧)󸛝󱾍󶻭 TPM 󲶿󾇄󳌣󱿖󳧼󱯤󱝤󷛇󳕅󴇠󲡖󶳩󷐽󲃅

󵫞󴰢

1

2 14

13

1 LPC Clock 2 3V Standby power

3 LPC Reset 4 3.3V Power

5 LPC address & data pin0 6 Serial IRQ

7 LPC address & data pin1 8 5V Power

9 LPC address & data pin2 10 No Pin

11 LPC address & data pin3 12 Ground

13 LPC Frame 14 Ground
