YOUR APPLIANCE HAS 2 OPERATING MODES:

• Automatic program mode:

Speed, cooking temperature and duration are

pre-programmed to make sauces, soups, stews,

steamed dishes, pastry and desserts automatically.

• Manual mode:

You can manually set the speed, cooking

temperature and duration.

YOUR APPLIANCE FEATURES A SAFETY LOCK ON

THE LID

The lid will lock every time the appliance is switched

on. This safety device stops the lid opening while a

recipe is being made (see Fig.16).

Do not try and force the lid when it is locked.

This safety device will unlock when the appliance

stops.

If you have selected a temperature over or equal to

50°C and a speed higher than or equal to 5, a 10

second countdown will appear on the LCD screen on

the control panel. (see Fig.17).

The lid can only be opened at the end of the

countdown.

INSTALLING THE BOWL, ACCESSORIES AND THE

LID ASSEMBLY

• Before using for the ﬁrst time, wash all items (D,

E, F, G) in warm soapy water, but not the motor

unit (A). Your bowl (D) is ﬁtted with a detachable

spindle (D3) for easier cleaning.

• Ensure that all packaging has been removed before

use, particularly the protection located between

the bowl (D) and the motor unit (A).

• Fit the seal (E4) on the seal holder (E3) (See Fig.

1), clip the assembly to the lid (E2) (See Fig 2).

• Position the seal (D4) on the spindle (D3). Lock

the assembly onto the base of the bowl with the

locking ring (D5) (See Fig. 3). If you use the

cooking mode without a lid, position the gasket

(D4) over the detachable spindle (D3). Use the

locking ring to lock the assembly to the bottom of

the bowl (D5) (see Fig. 3).

• Position the chosen accessory in the bowl:

- the accessories (F1, F2, F3, or F4) ﬁt on the

spindle (See Fig. 4.1),

- the steam basket inside the bowl (F5), (See

Fig. 4.3 ),

having taken care beforehand to ﬁll

the bowl (F5) with 0.7l liquid (water,sauce...)

(See Fig. 4.2).

• Place the ingredients into the bowl or steam

basket.

• Position the lid with the arrow on the lid handle

on the left side. Align the triangle on the lid with

the triangle on the bowl handle (See Fig. 5).

Lock the lid by turning anticlockwise (See

Fig. 6).

• Position the steam regulator cap (E1) on the lid;

two positions are possible: high steam (a) or low

steam (b).

• Position the bowl (D) on the motor unit (A) until

you hear a “click” (See Fig. 8).

• The appliance only starts up if the bowl and the lid

are correctly positioned and locked on the motor

unit.

In the event of incorrect positioning or

incorrect locking of either (See Fig. 10.1

and 10.2), the logo

starts to ﬂash when

a function is activated.

Steam

basket

The cooking times for the steam basket are provided as a guide - in most cases they are a

reliable indicator of cooking times. However, certain factors will impact cooking times; the

size of vegetables (cut or uncut)/quantity of ingredients in the basket/variety and ripeness

of vegetables/amount of water in the bowl, which must correspond to the markings (0.7 l).

Ensure that the steam regulator cap is turned in the "max." direction (a). If the food is not

sufﬁciently cooked, you can add extra cooking time.

Steaming vegetables, ﬁsh

or meat

20/40 min

1 kg

Chunky soups

3 min

3 l

P1 - Courgettes 20 min 800 g

P1 - Parsnips 25 min 800 g

P1 - Stem of a leek 25 min 800 g

P1 - Broccoli 20 min 500 g

P1 - Fish 15 min

600 g (incl.

baking paper)

P2 - Potatoes 30 min 1 kg

P2 - Carrots 30 min 1 kg

P2 - Green beans 30 min 800 g

P2 - White meat 20 min

600 g (incl.

baking paper)

Detachable spindle

You can brown food in the bowl without the lid on, allowing you to stir the

food and monitor the cooking process

The COOKING WITHOUT LID function is not suitable for jams or milk-based

mixtures (risk of spillage)

OPERATION UP TO 130°C

OPERATION FROM

135°C TO 150°C

Cooking with or without

the lid

Open lid only

Accessories

All accessories for use

with the spindle

Only detachable

spindle

Speed Yes No

Maximum time

- If the temperature is lower

than or equal to 100°C: 2 hr

- If the temperature is between

100°C and 130°C: 1 hr

- If the temperature

is higher than or

equal to 135°C:

20 min

!! Do not remove detachable spindle immediately after using it. Pour water into

the empty bowl to cool it down
