YOUR APPLIANCE

Your appliance is ﬁtted with an On/Off switch (H), set the switch to on. (See Fig. 9). Your appliance

goes into standby mode after 15 minutes of inactivity You can reactivate the appliance by pressing

the start/stop button. If you unplug and then quickly reconnect the appliance, it may remain in

standby mode. To switch off the appliance completely, use switch (H).

You have the following accessories with your appliance:

The following accessories are provided with your appliance:

These accessories also feature gripping areas to make them easier to use during recipe preparation.

max

Chopping blade

Mixing soups

3 min 3L

Mixing fruit purées

40 secs 1kg

Chopping vegetables

15 secs 1kg

Chopping meat

30 secs 1kg

Chopping ﬁsh

15 secs 1kg

Do not use this accessory to chop hard ingredients; use the E4 kneading/grinding blade.

Mixer

This mixes cooked foods without damaging the ingredients

This is very useful for browning stages early on during recipe preparation (risottos, soups)

Browning

5 min 500g

Stews

45 min 3 l

Risottos

22 min 1.5 kg

Ratatouille, chutneys, pulses (for settings see recipe booklet)

Whisk

9 max

Whisked egg white

5/10 min

max

Mayonnaise, whipped cream

2/5 min 0.5 l

Sauces, creams

1/20 min 1 l

Mashed potatoes

1 min 1 l

Polenta

1/16 min 1 l

Kneading/grinding blade

Kneading white bread dough

2 min

30 secs

1.2 kg

Kneading short crust pastry, biscuit

dough, speciality bread

2 min

30 secs

1 kg

Kneading rich dough

(brioche, kugelhopf etc.)

1 min 30 secs

2 min

0.8 kg

Mixing light batters

(cakes etc.)

40 secs

3 min

1 kg

Crushing nuts

1 min 0.6 kg

Chopping hard ingredients

1 min 0.6 kg

Crushing ice

1 min

6 to 10

Pancake batter, wafﬂe batter

1 min 1,5 l

Cap

Steam regulator cap

Max. (a) = steam cooking

Min. (b) = risotto, cream desserts, sauces etc.

The «min.» position allows the maximum amount of

condensation to escape, giving dishes or sauces a

better consistency (risotto, cream desserts, sauces etc.)

The «max.» position retains the maximum amount of heat and

steam in the bowl for all cooking functions using steam (soups etc.)

This position also prevents splashing when mixing

Thank you for choosing this appliance that is intended exclusively for the preparation of food in a

domestic environment, within the household.

On reading this instruction manual, you will ﬁnd recommendations for use, which will help

you see the potential of your appliance: preparation of sauces, soups, stews, steamed

dishes, pastries and desserts.

APPLIANCE DESCRIPTION:

A Motor unit

B Control panel

B1: Automatic program selection

buttons

B2: Speed selector

B3: Cooking temperature selector

and/or heating light indicator

B4: Operating time selector

B5: Turbo/pulse selector

B6: +/- selector

B7: Start/stop/reset button

B8: Connection indicator display*

C LCD screen

C1: Speed display

C2: Temperature display

C3: Time display

C4: Program selection display

C5: Safety indicator display

D Bowl assembly

D1: Stainless steel bowl

D2: Locks (located under handles)

D3: Detachable spindle

D4: Bowl seal

D5: Spindle locking ring

E Lid assembly

E1: Steam regulator cap/stopper

E2: Lid

E3: Seal holder

E4: Lid seal

F Accessories:

F0: Accessory storage box

F1: Ultrablade chopping knife

F2: Mixer

F3: Whisk

F4: Kneading and grinding blade

F5: Steam basket

G Spatula

H On/Off Switch: marked 0/1 switches the

power supply to your appliance

I Cleaning brush

APPLIANCE TECHNICAL DATA:

Power: 1550W (1000W: heating element / 550W: motor)

Temperature range: 30°C to 150°C

adjustable in steps of 5°C.

Operating duration range: 5 sec to 2 hours

adjustable in steps of 5 sec min to 1 min max.

Number of speeds: 13 - 2 intermittent speeds:

speed 1 (5 sec On / 20 sec Off).

speed 2 (10 sec On / 10 sec Off).

- 10 progressive continuous speeds (speeds 3 to 12).

- 1 max intermittent speed (speed 13).

Standby mode: Power consumption when the product is in

standby mode: 0.5 Wh

- *The Bluetooth

brand and logos are registered brands of Bluetooth SIG, Inc. and their use by the SEB Group has been ofﬁcially authorised.

- Google Play and Android are Google Inc. brands.

- Apple and the Apple logo are Apple Inc. brands, registered in the USA and other countries. App Store is an Apple Inc. service mark.
