MOTION CMD-02 TUBULAR MOTOR
MOTION CMD-02 TUBULAR MOTOR
Frequently Asked Questions
Problem Cause Solution
Blind does not work.
Motor is not activated
Activate the motor. See step 1.
Motor battery is empty. Charge the motor. See step 18.
Remote battery is empty. (LEDS of remote
are flashing rapidly.)
Replace the battery in the remote.
See the manual of the remote.
Remote battery is inserted incorrectly.
Replace the battery in the remote.
See the manual of the remote.
Radio-frequency interference Make sure that the antenna of the motor is
out of the way of metal objects.
The distance from the remote to
the motor is too far.
Move closer to the motor.
The remote is not connected to
the blind.
Pair the remote with the motor.
See step 6.
Motor LED flashes red. The battery of the motor is empty. Charge the motor. See step 19.
Blind is not charging.
Charger is not plugged in or does not work.
Try a different charger or make sure the
charger is plugged in the outlet.
Blind moves in small steps. No end limits are programmed. Program end limits. See step 8 - 11.
Favourite position can not
be programmed.
No end limits are programmed. Program end limits . See step 8 - 11.
Blind lowers too far. End limits are programmed incorrectly. Reprogram end limits. See step 8 - 11.
Blind moves in the opposite
direction
The rotational direction has been
set incorrectly.
Change the rotational direction.
See step 7
The blind keeps moving up and
down.
The blind is in program mode.
Press the program button on the motor
to exit program mode.
18
LED light flashes
red during operation;
Charge the battery
LED light flashes
green;
battery is charging
LED light constantly
green;
battery is fully charged
Recharge the battery
Use a micro USB cable to charge the motor.
