Web Browser Firmware Update
It is possible to update the rmware in the S200 via its web page.
There are a number of ways to do this and these are listed below:
i. Via Safari. If you have safari web browser installed, click
on Bonjour and then the bookmarks tab. The S200 should
appear as one of the bookmarks in Bonjour. Continue to
step 1 below.
ii. Via Computer on a Windows 7 PC. Navigate to the
Computer (Start; Computer), and click on Network. Scroll
to Media Devices and double click on AIRSTREAM_S200
xxxxxx (Where xxxxxx is the last 6 digits of its unique MAC
address). Continue to Step 1 below.
iii. Via the Control Panel on a Windows 7 PC. Navigate to the
Control Panel and select Hardware and Sound, and then
Devices and Printers. AIRSTREAM_S200 xxxxxx should be
displayed under the Devices title. Double click to bring up
the Properties window. Click on the UPnP tab and then the
link next to “Webpage”. Continue to Step 1 below.
iv. Via any internet browser. This method can only be done
if the IP address of the S200 is known. If you do not
already know this, it can be found out by going to your
router’s control panel and looking under attached devices
(or similar). Refer to the router’s manual for help on this.
Continue to step 1 below.
v. Via any web browser. This method can only be done if the
last 6 digits of the MAC address are known. In the address
bar of the browser, type in the following:
http://airstream-s200-xxxxxx.local./index.asp
Where xxxxxx is the last 6 digits of the MAC address.
WARNING: Do not, at any point during the update
procedure remove the power from the S200, or click
back on the web browser. Follow the on screen
instructions and the instructions in this manual.
1. Download the updated rmware from the Airstream website
www.monitoraudio.com and save it to your
computer.
2. Connect to the S200 using one of the 5 methods outlined
above and click on the Firmware Update tab.
3. Click on the drop down menu next to ‘Update Method’ and
select the option “Firmware Update From Network”.
4. Click on Ok. The page will change with a note to say it should
refresh in a couple of seconds, or click a link. Click the link
(if it doesn’t refresh).
The LED on the S200 will ash white slowly and then turn
solid white.
5. Next, click on “Choose File” and navigate to the location the
updated rmware le was saved to. Select it and click open.
6. Click on “Upload”.
14
