6. Insert sensor module: Push the sensor module into its receptacle. The arrow on the back of the module
points to 9 o'clock when looking at the module as shown.
7. Lock the sensor module: Using the gray module wrench M.1, turn the sensor module clockwise until it
stops.
CAUTION! If you cannot turn the sensor module, it has been inserted the wrong way! Remove the
sensor module, rotate it by 180 degrees and insert it again.
8. Repeat steps 3 to 6 for the remaining sensor modules or the blind module 1.5, respectively.
Mounting
Installing an additional Sensor Module
37 / 87
