En-12
Wi-Fi INTERFACE SETTING UP (VGK TYPE ONLY)
This Wi-Fi interface, communicates the status information and controls
the commands from the server by connecting to the indoor unit.
Wi-Fi interface
Wi-Fi interface
Front panel
Front panel
Wi-Fi interface introduction
ERR
NET
MODE
UNIT
RESET
MODE
Wi-Fi
INTERFACE
MODEL
XXXXXXXX
MAC
ID
SSID
KEY
: XXXXXXXXXXXX
: XXXXXXXXXX
: XXXXXXXXXXXX
: XXXXXXXXXXXX
VOLTAGE
CURRENT
:
:
MITSUBISHI ELECTRIC CORPORATION
WiFi.ASSY DWG No.
XXXXXXXXXXX
MADE IN CHINA
XXXXXXXXXX
>PP<
3
4
5
6
2
1
Note:
WhentheWi-Fiinterfaceisresettothefactorydefault,ALLthe
congurationinformationwillbelost.Takegreatcareinimplementingthis
operation.
(2) RESET Button
• HolddowntheRESETButtonfor2secondstorebootthesystem.
• HolddowntheRESETButtonfor14secondstoinitialisetheWi-Fiinterface
to the factory default.
No Item Description
1
MODEButton Selects modes.
2
RESETButton ResetsthesystemandALLsettings.
3
ERRLED(Orange) Showsthenetworkerrorstate.
4
NETLED(Green) Showsthenetworkstate.
5
MODELED(Orange) ShowstheAccessPointModestate.
6
UNITLED(Green) Showstheindoorunitstate.
3
4
5
6
Information for users
ThefollowingstepsexplainhowtoconnecttheWi-FiinterfacetoaRouter.
1
2
THERE ARE TWO OPTIONS OF
CONNECTING
EnsuretheWi-Fiinterfaceisconnectedcorrectlyasper
theprevioussection,‘ConnectingtheWi-Fiinterface’.
UNITLEDshouldbeashinggreenonly.
: ON : Flashing : OFF
KEY (LED LIGHTS):
DownloadandinstallWi-FiControlApptoyour
compatible Apple or Android smartphone/tablet
(searchterm:MitsubishiWi-FiControl).
ActivateAccessPointModeonyour
Wi-Fi interface by using a small object to
pressandholdtheMODEButtonfor7
seconds.
WhenAccessPointModeisenabledontheWi-Fi
interface,MODELEDstartsashingorange(every5
seconds).
CompletethesettingupintheAccessPointModewith
in10minutes.
Option 1 - Access Point Mode Pairing
Scanthematrixbarcodefromthelabelontheback
oftheinterfacetoconnecttoitsnetwork.
Ifyoucan'tconnectthisWi-Fiinterface,checkthe
labelonthebackoftheinterfacefortheSSID.
OpentheWi-Finetworksscreenonyour
smartphone/tabletandconnecttothenetwork
withthesamenameastheSSID.Thenetwork
password,labelledKEY,isjustundertheSSIDon
the interface.
YouwillnowbeconnectedtothisWi-Fiinterface.
OpenWi-FiControlAppandfollowthe‘Howto
Setup’instructionsinthe‘SetupWi-Fiinterface’
section.
If the app does not go to this section, you are
notconnectedtotheWi-Fiinterface’sAccess
Point;pleasestartprocessagain.
YoucaneitherselectyouravailableWi-Fi
Network,ormanuallycongureaWi-FiNetwork.
ERR
NET
MODE
UNIT
RESET
MODE
ERR
NET
MODE
UNIT
RESET
MODE
(1) MODE Button
■
WPS-Push mode <For a router with a WPS button>
[To enter the mode
]
HolddowntheMODEButtonfor2seconds.
[LED indication]
WhenWPS-PushisenabledontheWi-Fiinterface,theMODELEDstarts
ashingorange(everysecond).
[Tocancelthemode]
HolddowntheRESETButtonfor2secondstoreturntotheinitialstate.
■
Access Point mode <For a router without a WPS button and to set up with a
smart phone
>
[
To enter the mode]
HolddowntheMODEButtonfor7seconds.
[LED indication]
WhenAccessPointmodeisenabledontheWi-Fiinterface,theMODELED
startsashingorange(every5seconds).
[
Tocancelthemode]
HolddowntheMODEButtonfor7secondsagainandensurethattheMODE
LEDisnolongerashing.
Inanymode,theNETLEDwillashwhentheWi-Fiinterfaceisconnectedto
the Router.
