Specications
Model
Indoor MFZ-KW25VGK-A1 MFZ-KW35VGK-A1 MFZ-KW42VGK-A1
Outdoor MUFZ-KW25VG2-A1 MUFZ-KW35VG2-A1 MUFZ-KW42VG2-A1
Function Cooling Heating Cooling Heating Cooling Heating
Power supply ~/N, 230 V, 50 Hz
Capacity kW 2.5 3.4 3.5 4.3 4.2 5.4
Input kW 0.57 0.78 0.87 1.14 1.11 1.43
Weight
Indoor kg 15
Outdoor kg 35
Refrigerant lling capacity (R32) kg 1.0
IP code
Indoor IP20
Outdoor IP24
Permissible excessive
operating pressure
LP ps MPa 2.77
HP ps MPa 4.17
Noise level
Indoor (Super High/
High/Med./Low./Quiet)
dB(A)
44/38/32/
26/20
44/38/31/
25/18
44/38/32/
26/20
44/38/31/
25/18
51/43/36/
28/20
51/44/36/
27/18
Outdoor dB(A) 48 46 48 47 48 47
Indoor
Outdoor
MUFZ-
KW25/35/42/50/60VG2
MUFZ-
KW50/60VGHZ2
Cooling
Upper limit
32°C DB
23°C WB
46°C DB
—
46°C DB
—
Lower limit
21°C DB
15°C WB
-10°C DB
—
-10°C DB
—
Heating
Upper limit
27°C DB
—
24°C DB
18°C WB
24°C DB
18°C WB
Lower limit
20°C DB
—
-15°C DB
-16°C WB
-25°C DB
-26°C WB
Note:
Rating condition
Cooling — Indoor: 27°C DB, 19°C WB
Outdoor: 35°C DB
Heating — Indoor: 20°C DB
Outdoor: 7°C DB, 6°C WB
Guaranteed operating range
DB: Dry Bulb
WB: Wet Bulb
Wi-Fi interface
Model MAC-588IF-E
Input Voltage DC12.7 V (from indoor unit)
Power consumption MAX. 2 W
Size H×W×D (mm) 73.5×41.5×18.5
Weight (g) 96 g (including cable)
Transmitter power level (MAX.)
20 dBm
@IEEE 802.11b
RF channel 1ch ~ 13ch (2412~2472 MHz)
Radio protocol IEEE 802.11b/g/n (20)
Encryption AES
Authentication WPA2-PSK
Length of cable (mm) 2,040
For Declaration of Conformity, please go to the website below.
http://www.mitsubishielectric.com/ldg/ibim/
Model
Indoor MFZ-KW50VGK-A1 MFZ-KW60VGK-A1
Outdoor MUFZ-KW50VG2-A1 MUFZ-KW50VGHZ2-A1 MUFZ-KW60VG2-A1 MUFZ-KW60VGHZ2-A1
Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating
Power supply ~/N, 230 V, 50 Hz
Capacity kW 5.0 5.8 5.0 5.8 6.1 6.5 6.1 6.5
Input kW 1.32 1.53 1.32 1.53 1.73 1.88 1.73 1.88
Weight
Indoor kg 15
Outdoor kg 54
Refrigerant lling capacity (R32) kg 1.3
IP code
Indoor IP20
Outdoor IP24
Permissible excessive
operating pressure
LP ps MPa 2.77
HP ps MPa 4.17
Noise level
Indoor (Super High/
High/Med./Low./Quiet)
dB(A)
44/39/35/
31/27
50/45/40/
35/29
44/39/35/
31/27
50/45/40/
35/29
53/46/39/
35/27
51/47/41/
35/29
53/46/39/
35/27
51/47/41/
35/29
Outdoor dB(A) 53 56 53 56 53 56 53 56
Wi-Fi interface setting information
Indoor unit model name
Indoor unit serial number
Outdoor unit model name
Outdoor unit serial number
Wi-Fi interface MAC address (MAC)
Wi-Fi interface serial number (ID)
Wi-Fi interface SSID (SSID)
Wi-Fi interface KEY (KEY)
System commissioning date
Wi-Fi interface installation date
Installer contact details
Name
Telephone number
● OPERATING INSTRUCTIONS ●
EN-15
