42 43
M18 BBPFP2 M18 BBPFP2-CST M18 BBPFP2-WST
5095 00 01 XXXXXX MJJJJ 5095 11 01 XXXXXX MJJJJ 5095 97 01 XXXXXX MJJJJ
18 V
15 l 15 l
7,3 m
9,6 bar / 140 PSI 4,1 bar / 60 PSI
20 ml 20 ml
0,15 mm 0,15 mm
> 0,15 mm > 0,15 mm
4,2 kg
8,33 ... 9,35 kg 8,03 ... 9,15 kg
23,33 ... 24,5 kg 23,03 ... 24,15 kg
-18 °C ... +50 °C
M18B...; M18HB...; M18FB
M12-18...; M1418...; M18...
72 dB(A) / 3 dB(A) 72 dB(A) / 3 dB(A)
80 dB(A) / 3 dB(A) 80 dB(A) / 3 dB(A)
0,81 m/s
2
/ 1,50 m/s
2
1,38 m/s
2
/ 1,50 m/s
2
ENGLISH
TECHNICAL DATA
Type
Production code
Battery voltage
Tank capacity
Flow rate see picture section page 22
*
Spray distance
Max working pressure
Residual tank
Mesh size fi ller fi lter
Mesh size suction fi lter
Weight base unit
Empty weight (including baseunit, tank, battery 2.0 ... 12.0 Ah)
Operation weight (including 15 l fl uid at 20 °C with battery 2.0 ... 12.0 Ah)
Recommended ambient operating temperature
Recommended battery types
Recommended charger
Noise Information:
Measured values determined according to EN 62841.
Typically, the A-weighted noise levels of the tool are:
Sound pressure level / Uncertainty K
Sound power level / Uncertainty K
Wear ear protectors.
Vibration Information:
Total vibration values (vector sum in the three axes) determined according to EN
62841.
Vibration emission value a
h
/ Uncertainty K
WARNING! Read all safety warnings, instructions, illustrations and
specifi cations provided with this power tool. Failure to follow all instructions listed
below may result in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
BACKPACK SPRAYER SAFETY WARNINGS
"Read, understand, and follow all instructions on the machine and in the manual(s)
before operating this unit. Be thoroughly familiar with the controls and the proper use
of the machine. Know how to stop the unit and disengage the controls quickly.
Never allow children to operate the machine. Never allow adults to operate the
machine without proper instruction.
Keep the area of operation clear of all persons, particularly small children.
Exercise caution to avoid slipping or falling."
Do not spray fl ammable liquids, such as gasoline, to reduce the risk of fi re or
explosion.
Always follow the chemical manufacturer’s instructions printed on their product
labeling for use, cleaning, and storage. Chemicals should be stored out of the reach
of children.
Do not spray any material where the hazard is not known.
To reduce exposure to spray materials, wear approved safety equipment, such as
face mask designed for spraying, gloves, and other appropriate protective equipment.
Do not use fl ammable solvents or abrasive cleaning agents to clean the product.
Keep spray materials away from eyes. If spray materials come in contact with the
eyes, wash them immediately with clean water. If irritation is still present, immediately
seek medical help.
During fi lling and emptying power unit needs to be removed from the tank.
ADDITIONAL SAFETY AND WORKING INSTRUCTIONS
Be aware of any hazards presented by the material being sprayed and instruction to
consult the markings on the container or the information supplied by the manufacturer
of the material to be sprayed.
Keep the area clear of all bystanders, children, and pets while spraying.
Do not use the product when you are tired, ill, or under the infl uence of alcohol, drugs,
or medication.
Ensure that the spray wand is securely connected to the spray wand handle before
using the product. If necessary, use pliers to attach the spray wand to the spray wand
handle.
Remember to properly replace and tighten the spray tank cover after pouring liquid
into the spray tank.
Use only consumer-grade water-based lawn and garden chemicals.
Do not use commercial-grade chemicals or chemicals for commercial or industrial
purposes.
Do not use caustic (alkali) self-heating or corrosive (acid) liquids with the product.
These can corrode metal parts or weaken the tank and hose.
Do not leave residue or spray material in the spray tank after using the product. Clean
Backpack Sprayer Backpack Sprayer Backpack Sprayer
ENGLISH
after each use.
Do not pour hot or boiling liquids into the spray tank. These can weaken or damage
the hose or spray tank.
Do not overfi ll the tank.
Always check for leaks. If any are found, correct them before using the product.
The spray area must be well ventilated.
Always inspect both the inside and outside of the product before each use.
Liquids to be sprayed must be as thin as water. Thicker liquids will not spray properly.
Spray materials may be premixed and poured into the spray tank using a funnel.
Do not spray where spark, fl ame, or other source of ignition is present.
Do not spray in the direction of people or animals. Always spray downwind.
Do not smoke, eat, or drink while using the product.
Do not discharge directly against skin.
Do not let the spray materials come in contact with skin. If contact does occur, wash
immediately with soap and plenty of water.
Aim the nozzle directly at the plants or objects you intend to spray.
Ensure that the spray materials are directed at an area that will not be damaged by
the spray materials.
Avoid spraying on windy days. The spray materials can be accidentally blown onto
plants or objects that should not be sprayed.
The product may be operated with the spray wand handle resting in the cradle, or
may be rem oved from the cradle and be held by the operator.
Electric shock hazard. Do not spray towards electrical outlets.
After every use, thoroughly wash your hands and any area where skin has been
exposed to the spray.
Maintain the product. Thoroughly inspect both the inside and outside of the product
and examine the components before each use. Check for cracked and deteriorated
hoses, leaks, clogged nozzles, and missing or damaged parts. If damaged, have
the product repaired before use. Many accidents are caused by poorly maintained
products.
Wear personal protective equipment (PPE) according to the chemical manufacturers
instructions.
Remove the battery from the product before draining, cleaning, or storing to avoid
accidental starting.
Mix the chemicals strictly in accordance with the manufacturer’s instructions. Incorrect
mixtures may produce toxic fumes or explosive solutions.
Never allow children, persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge or people unfamiliar with these instructions to use
the machine, local regulations may restrict the age of the operator.
Remove the battery pack before starting any work on the machine.
Do not dispose of used battery packs in the household refuse or by burning them.
Milwaukee Distributors off er to retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects (short circuit risk).
Use only compatible Milwaukee chargers from the same battery platform for charging
batteries. Do not use batteries from other systems.
Battery acid may leak from damaged batteries under extreme load or extreme
temperatures. In case of contact with battery acid wash it off immediately with
soap and water. In case of eye contact rinse thoroughly for at least 10 minutes and
immediately seek medical attention.
Warning! To reduce the risk of fi re, personal injury, and product damage due to a
short circuit, never immerse your tool, battery pack or charger in fl uid or allow a fl uid
to fl ow inside them. Corrosive or conductive fl uids, such as seawater, certain industrial
chemicals, and bleach or bleach containing products, etc., can cause a short circuit.
SPECIFIED CONDITIONS OF USE
The backpack sprayer is intended for outdoor use in a well-ventilated area.
M18 BBPFP2-WST:
The sprayer is designed for spraying water and may also be used to water plants.
M18 BBPFP2-CST:
The sprayer is designed for spraying consumer-grade home and garden chemicals
such as:
• Pesticides
• Selective Herbicides
• Non-Selective Herbicides
• Insecticides
• Fungicides
• Fertilizers
This sprayer shall be used only with plant protection products approved by local/
national regulatory authorities for plant protection products.
Do not use the sprayer with fl ammable liquids.
Use only substances approved for use with portable sprayers.
Do not use the sprayers for any purpose not listed above. The sprayer is not to be
used by children or by persons not wearing adequate personal protective equipment
and clothing.
Do not use this product in any other way as stated for normal use.
RESIDUAL RISKS
Even when the product is used as prescribed, it is still impossible to completely
eliminate certain residual risk factors. The following hazards may arise and the
operator should pay special attention to avoid the following:
Electric shock. Never spray liquid towards electrical sockets, cables, or appliances.
Contact with hazardous substances. Spray materials may be harmful if inhaled,
ingested, or comes in contact with skin or eyes. Follow instructions carefully and wear
appropriate protective equipment as prescribed in this manual.
NOTES FOR LI-ION BATTERIES
Use of Li-Ion batteries
Battery packs which have not been used for some time should be recharged before
use.
Temperatures in excess of 50°C reduce the performance of the battery pack. Avoid
extended exposure to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the battery packs have to be fully charged, after used.
To obtain the longest possible battery life remove the battery pack from the charger
once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C and away from moisture
Store the battery packs in a 30% - 50% charged condition
Every six months of storage, charge the pack as normal.
Battery protection for Li-Ion Akkus
In extremely high torque, binding, stalling and short circuit situations that cause high
current draw, the tool will vibrate for about 5 seconds, the fuel gauge will fl ash,and
then the tool will turn OFF. To reset, release the trigger.
Under extreme circumstances, the internal temperature of the battery pack could raise
too much. If this happens, the fuel gauge will fl ash until the battery pack cooled down.
After the lights go off , the work may continue.
Transport of Lithium Batteries
Lithium-ion batteries are subject to the Dangerous Goods Legislation requirements.
Transportation of those batteries has to be done in accordance with local, national and
international provisions and regulations.
• The user can transport the batteries by road without further requirements.
• Commercial transport of Lithium-Ion batteries by third parties is subject to
Dangerous Goods regulations. Transport preparation and transport are exclusively
to be carried out by appropriately trained persons and the process has to be
accompanied by corresponding experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and insulated to prevent short
circuit.
• Ensure that battery pack is secured against movement within packaging.
• Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice.
* The fl ow rate depends on the spray medium used, the fl ow height and environmental infl uences such as wind conditions.
WARNING
The vibration and noise emission level given in this information sheet has been measured in accordance with a standardized test given in EN 62841 and may be used to
compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration and noise emission level represents the main applications of the tool. However if the tool is used for diff erent applications, with diff erent accessories or
poorly maintained, the vibration and noise emission may diff er. This may signifi cantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration and noise should also take into account the times when the tool is switched off or when it is running but not actually doing the
job. This may signifi cantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eff ects of vibration and/or noise such as: maintain the tool and the accessories, keep the hands warm,
organization of work patterns.
