18 19

M18 AFG2

5035 49 01 XXXXXX MJJJJ

18 V

18 V / 2 A / 36 W

100 - 240 V ~ 50/60 Hz / 1 A / 40 W

1444 m

/h (850 CFM)

2,91 kg

3,34 kg ... 4,40 kg

-18...+40 °C

M18B...; M18HB...; M18FB

M12-18C, M12-18AC, M12-18FC, M1418C6

59,31 db(A) / 3 dB(A)

71,80 dB(A) / 3 dB(A)

ENGLISH ENGLISH

TECHNICAL DATA

Type

Production code

Battery voltage

DC Input

AC Input

Air delivery rate max.

Weight without battery

Weight according EPTA-Procedure 01/2014 (2.0 Ah ... 12.0 Ah)

Recommended ambient operating temperature

Recommended battery types

Recommended charger

Noise information:

Measured values determined according to EN IEC 60704.

Typically, the A-weighted noise levels of the tool are:

Sound pressure level / Uncertainty K

Sound power level / Uncertainty K

WARNING Read all safety warnings, instructions, illustrations

and speciﬁ cations provided with this power tool. Failure to follow all

instructions listed below may result in electric shock, ﬁ re and/or serious

injury.

Save all warnings and instructions for future reference.

FAN SAFETY WARNINGS

This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without

supervision.

Use only AC cable provided by the manufacturer.

Do not use the appliance near naked ﬂ ames or glowing ashes.

Do not use the device in rooms with a potentially explosive atmosphere.

Do not use the device in rooms in which easily ﬂ ammable material or gases

may be present.

Do not leave the appliance unsupervised when it is switched on.

Do not use the device outside if it is raining.

Never close or block the air grille. Do not block the fan impeller.

Do not use the fan without the fan grille or if the fan grille is defective.

Only use the appliance in a well ventilated area.

Dress properly. Do not wear loose clothing or jewelry, they can be caught in

moving parts.

Loose clothing, jewels and long hair may get caught by moving parts.

Rechargeable batteries are to be removed from the appliance before being

charged.

If the appliance is to be stored unused for a long period, the batteries should

be removed.

The supply terminals are not to be short-circuited.

Remove the battery pack before starting any work on the machine.

Do not dispose of used battery packs in the household refuse or by burning

them. Milwaukee Distributors oﬀ er to retrieve old batteries to protect our

environment.

Do not store the battery pack together with metal objects (short circuit risk).

Use only compatible Milwaukee chargers from the same battery platform for

charging batteries. Do not use batteries from other systems.

Battery acid may leak from damaged batteries under extreme load or

extreme temperatures. In case of contact with battery acid wash it oﬀ

immediately with soap and water. In case of eye contact rinse thoroughly for

at least 10 minutes and immediately seek medical attention.

Warning! To reduce the risk of ﬁ re, personal injury, and product damage

due to a short circuit, never immerse your tool, battery pack or charger in

ﬂ uid or allow a ﬂ uid to ﬂ ow inside them. Corrosive or conductive ﬂ uids, such

as seawater, certain industrial chemicals, and bleach or bleach containing

products, etc., can cause a short circuit.

SPECIFIED CONDITIONS OF USE

This machine is intended for commercial use, for example in hotels, schools,

hospitals, factories, shops, oﬃ ces and rental businesses.

Do not use this product in any other way as stated for normal use.

NOTES FOR LI-ION BATTERIES

Use of Li-Ion batteries

Batteries which have not been used for some time should be recharged

before use.

Temperatures in excess of 50°C (122°F) reduce the performance of the

battery. Avoid extended exposure to heat or sunshine (risk of overheating).

The contacts of chargers and battery packs must be kept clean.

For an optimum life-time, the batteries have to be fully charged, after used.

To obtain the longest possible battery life remove the battery pack from the

charger once it is fully charged.

For battery storage longer than 30 days:

Store the battery where the temperature is below 27°C and away from

moisture.

Store the battery in a 30% - 50% charged condition.

Every six months of storage, charge the battery as normal.

Battery protection for Li-Ion batteries

In extremely high torque, binding, stalling and short circuit situations that

cause high current draw, the tool will vibrate for about 5 seconds, the fuel

gauge will ﬂ ash,and then the tool will turn OFF. To reset, release the trigger.

Under extreme circumstances, the internal temperature of the battery pack

could raise too much. If this happens, the fuel gauge will ﬂ ash until the

battery pack cooled down. After the lights go oﬀ , the work may continue.

Transport of Li-Ion batteries

Lithium-ion batteries are subject to the Dangerous Goods Legislation

requirements.

Transportation of those batteries has to be done in accordance with local,

national and international provisions and regulations.

• The user can transport the batteries by road without further requirements.

• Commercial transport of Lithium-Ion batteries by third parties is subject

to Dangerous Goods regulations. Transport preparation and transport

are exclusively to be carried out by appropriately trained persons and the

process has to be accompanied by corresponding experts.

When transporting batteries:

• Ensure that battery contact terminals are protected and insulated to

prevent short circuit.

• Ensure that battery pack is secured against movement within packaging.

• Do not transport batteries that are cracked or leak.

Check with forwarding company for further advice

MAINS CONNECTION

Connect only to single-phase AC system voltage as indicated on the rating

plate. It is also possible to connect to sockets without an earthing contact as

the design conforms to safety class II.

Before doing any work on the device pull the plug out of the socket.

Make sure the machine is switched oﬀ before plugging in.

Before use check machine, cable and plug for any damages or material

fatigue. Repairs should only be carried out by authorised Service Agents.

Keep mains lead clear from working range of the machine. Always lead the

cable away behind you.

Always disconnect the plug from the socket after use.

CLEANING

Dust or wipe grill with a mild soap. Do not place grill in a dishwasher.

Excessive heat can distort the plastic.

Wipe blades with a damp cloth. Do not remove blades. If fan is used in a

greasy environment, such as a kitchen, mild soap or a common household

cleaner may be necessary. Do not use solvents. Do not place in a

dishwasher. Excessive heat can distort the plastic.

Always reinstall the front grill before use.

MAINTENANCE

If the replacement of the supply cord is necessary, this has to be done by the

manufacturer or his agent in order to avoid a safety hazard.

Use only Milwaukee accessories and Milwaukee spare parts. Should

components need to be replaced which have not been described, please

contact one of our Milwaukee service agents (see our list of guarantee/

service addresses).

If needed, an exploded view of the tool can be ordered. Please state the

machine type printed as well as the six-digit No. on the label and order the

drawing at your local service agents or directly at: Techtronic Industries

GmbH, Max-Eyth-Straße 10, 71364 Winnenden, Germany.

SYMBOLS

Please read the instructions carefully before starting the

machine.

CAUTION! WARNING! DANGER!

Remove the battery pack before starting any work on the

machine.

This tool is only suitable for indoor use. Never expose tool

to rain.

Class II tool.

Qualiﬁ ed for tropical climate up to 40°C ambient temperature

Do not dispose of waste batteries, waste electrical and

electronic equipment as unsorted municipal waste. Waste

batteries and waste electrical and electronic equipment must

be collected separately.

Waste batteries, waste accumulators and light sources have

to be removed from equipment.

Check with your local authority or retailer for recycling advice

and collection point.

According to local regulations retailers may have an

obligation to take back waste batteries and Waste electrical

and electronic equipment free of charge.

Your contribution to re-use and recycling of waste batteries

and waste electrical and electronic equipment helps to

reduce the demand of raw materials.

Waste batteries, in particular containing lithium and waste

Electrical and electronic equipment contain valuable,

recyclable materials, which can adversely impact the

environment and the human health, if not disposed of in an

environmentally compatible manner.

Delete personal data from waste equipment, if any.

No-load-speed

Voltage

Direct Current

European Conformity Mark

UK Conformity Mark

Ukraine Conformity Mark

EurAsian Conformity Mark

Battery-powered fan

WARNING!

The noise emission level given in this information sheet has been measured in accordance with a standardized test given in EN IEC 60704 and may be used to

compare one tool with another. It may be used for a preliminary assessment of exposure.

The declared noise emission level represents the main applications of the tool. However if the tool is used for diﬀ erent applications, with diﬀ erent accessories

or poorly maintained, noise emission may diﬀ er. This may signiﬁ cantly increase the exposure level over the total working period.

An estimation of the level of exposure to noise should also take into account the times when the tool is switched oﬀ or when it is running but not actually doing

the job. This may signiﬁ cantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the eﬀ ects of noise such as: maintain the tool and the accessories and organization of work

patterns.
