23
Installation checklist
1. Location
2.
Water System Piping
The flooring beneath the water heater must be able to support the weight of the
unit when filled with water (more than 445kg).
Located outdoors and in a vertical position. Sheltered from freezing temperatures.
Provisions made to shelter the area from water damage. Metal drain pan installed
and piped to an adequate drain.
Sucient room to service the water heater.
Sucient air for the heat pump to function, the water heater must be located in a
space >15m, and must have unrestricted air flow.
Water Quality.
●
The unit cannot be placed into any type of closet or small enclosure.
The site location must be free from any corrosive elements in the atmosphere such as
sulfur, fluorine, and chlorine. These elements are found in aerosol sprays, detergents,
bleaches, cleaning solvents, air fresheners, paint, and varnish removers, refrigerants,
and many other commercial and household products. In addition excessive dust and
may aect the operation of the unit and require frequent cleaning.
The ambient air temperature must be above -7
˚
C and below 43
˚
C. If the ambient air
temperature falls outside these upper and lower limits the electrical elements will be
activated to meet the hot water demand.
PRT (Temperature and pressure relief valve) properly installed with a discharge pipe
run to an adequate drain and sheltered from freezing.
All piping properly installed and free of leaks. Unit completely filled with water.
Tempering valve installed per manufacturer’s instructions.
●
●
●
●
●
3. Condensate Drain Line Installation
Must be located with access to an adequate drain or condensate pump.
Condensate drain lines installed and piped to an adequate drain or condensate pump.
●
●
●
●
●
●
●
Not
Applicable
Not
Applicable
2500* 200
6.5
to
9.5
+0.4to-1.0@
65˚C
*For TDS levels up to and including 800mg/litre the magnesium based anode is to
be used. It is recommended that magnesium anode be checked annually.This is
the anode fitted during manufacture of the cylinder. For TDS levels greater than
800mg/litre and not exceeding 2500mg/litre the magnesium based anode is to be
used. Frequently inspection of magnesium anode is recommended.This anode Can
be fitted by midea or an authorized person. This Warranty does not apply if the
TDS exceeds 2500 mg/litre.
Water
heater
system
Total Disso-
lved Solids
(TDS)mg/L
or ppm
Hardness
(as CaCO3)
mg/L or ppm
Saturation
index
(Langelier)
PH
Dissolved
Co2 mg/L
or ppm
Chlorides
mg/L or ppm
NOTE
For optimal eciency and serviceability, the following clearances should be
maintained: 800mm on the air inlet side, 800mm on the air outlet side, 600mm
in the back, and 600mm in the front.
