Electronic Work
WARNING:
BEFORE PERFORMING ANY ELECTRICAL OR WIRING WORK, TURN OFF THE
MAIN POWER TO THE SYSTEM.
Main Control
Compressor
Fan Motor
Display
Power
Supply
L/AC L/L1/L-IN
N/AC N/L2/N-IN
Other
Electronic Type
NOTE:
Please strictly follow the wiring label attached to the machine for all wiring connections. The
the machine you have purchased. The above wiring diagram is a simplified version for preliminary
illustration purposes only.
