FIGURE J
INSTALLING DOORS
Pre-Installed Bumpers
(3x Replacement Bumpers Provided)
FIGURE K
FOR 3-BAY MODELS ONLY: Follow the step listed below to install the middle and right doors to the
metal frame of your credenza. Middle and right doors follow the same orientation.
NOTE: If using an electric drill, verify the torque is on the lightest setting and only increase as neces-
sary.
• Use (2x) 10-32 x ½” machine screws (F) to attach door to the metal frame, as shown. (FIGURE K)
Page 11
FOR ALL MODELS: Follow the step listed below to install the outer doors to the wood side panels.
NOTE: If using an electric drill, verify the torque is on the lightest setting and only increase as neces-
sary.
• Use (2x) #6 x ½” wood
screws (E) per side, to
attach the door(s) to the
wood side panel, as
shown. (FIGURE J)
