FlashPro Express User Guide
51
The following table shows sample SPI Flash programming times (all using PPD flow)
SPI Flash Programming
Splash Kit
(N25Q00AA13GSF40G /
MT25QL01GBBB8ESF-
0SIT TR)
1
10MByte
data
PPD Programming
Time
FlashPro
5
4
FlashPro
6
2
TCK = 4MHZ TCK = 15MHz
3
TCK = 4MHZ TCK =
15MHz
3
TCK =
20MHz
3
USB 2.0
USB 2.0
USB 2.0/3.0
USB 2.0/3.0
USB 2.0/3.0
Program SPI Flash 8min 30sec 5min 29sec 22min 12sec 13min 9sec 12min 11sec
Verify SPI Flash 2hrs 22min 10sec 2hrs 10min 28sec 23min 05sec 14min 17sec 13min 21sec
Read SPI Flash
2hrs 34min 20sec
2hrs 23min 45sec
22min 30sec
13min 54sec
12min 55sec
Erase SPI Flash 19sec 18sec 1min 51sec 1min 49sec 1min 48sec
Notes:
1
SPI Flash programming has been tested on N25Q00AA and MT25QL01G/MT25QU01G
devices only. Contact technical support for other SPI-Flash device support needs.
2
FlashPro6 has longer programming times for SPI Flash devices, when compared to
FlashPro5. However, readback and verification times are significantly shorter. Programming
time for FlashPro6 will be improved in future releases.
3
To successfully program the device at a high TCK frequency, appropriate steps must
be taken to ensure signal integrity of the JTAG signals.
4
FlashPro5 supports MT25QL01G and N25Q00AA13Gxx40G only.
