FlashPro Express User Guide
50
Appendix A: Sample Programming and
SmartDebug Times Using
FlashPro5/FlashPro6
The tables in this appendix show sample programming times using FlashPro5 and FlashPro6
programmers.
The following table shows sample PPD programming times.
Devices
1
PPD Programming Time
2
(mm:ss)
FlashPro5 FlashPro6
TCK=4MHz TCK=4MHz TCK=20MHz
3
USB 2.0 USB 2.0/3.0 USB 2.0/3.0
M2S/A2GL 005
M2S/A2GL 010
M2S/A2GL 025
M2S/A2GL 050 2min 9sec 2min 10sec 2min 2sec
M2S/A2GL 060
M2S/A2GL 090
M2S/A2GL 150 4min 21sec 4min 19sec 3min 54sec
RTG4 2min 10sec 1min 56sec 1min 33sec
MPF100 39sec 28sec 23sec
MPF200 1min 3sec 43sec 28sec
MPF300 1min 33sec 1min 4sec 43sec
MPF500 1min 57sec 1min 34sec 1min
Notes:
1
FlashPro6 supports JTAG programming for all SmartFusion2, IGLOO2, RTG4 and PolarFire devices.
2
To benefit from the improved programming time using FlashPro6, use the PPD file format for
SmartFusion2, IGLOO2 and PolarFire devices. Programming time speed up with PPD will be added in
future releases.
3
To ensure successful programming at 20MHz TCK, appropriate steps need to be taken to ensure signal
integrity of the JTAG signals.
