FlashPro Express User Guide
39
Error
Code
Exit
Code
Exit Message Possible Cause Possible Solution
0x8027
0x8028
10 Authentication Error
Bitstream and device
mismatch
Libero device selection does
not match the target device.
Generate a programming file with the
correct device selection for the target
device.
0x8007
0x804C
11 Failed to verify FPGA
Array
Failed to verify Fabric
Configuration
Failed to verify Security
Device is programmed with a
different design or the
component is blank.
Unstable voltage level.
Signal integrity issues on
JTAG pins.
Verify the device is programmed with the
correct data/design.
Monitor related power supplies that cause
the issue during programming; check for
transients outside of Microsemi
specifications. See your device datasheet
for more information on transient
specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for
noise or reflection.
0x8008
0x8009
0x8049
11 Failed to verify eNVM Device is programmed with a
different design.
Unstable voltage level.
Signal integrity issues on
JTAG pins.
Verify the device is programmed with the
correct data/design.
Monitor related power supplies that cause
the issue during programming; check for
transients outside of Microsemi
specifications. See your device datasheet
for more information on transient
specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for
noise or reflection.
0x8013 -18 Digest request from
SPI/JTAG is protected by
User Pass Key 1
Digest request from SPI/JTAG
is protected by user pass key
1. Lock bit has been
configured in the Debug Policy
within SPM (Security Policy
Manager)
Provide a programming file with a pass
key that matches pass key programmed
into the device.
0x8014 -19 Failed to verify digest >Unstable voltage level
Signal integrity issues on
JTAG pins
Monitor related power supplies that cause
the issue during programming; check for
transients outside of Microsemi
specifications. See your device datasheet
for more information on transient
specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for
noise or reflection.
