FlashPro Express User Guide
38
Exit Codes (SmartFusion2 and IGLOO2)
Error
Code
Exit
Code
Exit Message Possible Cause Possible Solution
0
Passed (no error)
-
-
0x8002
5
Failure to configure
device programming at
1.2/1.0 VCC voltage
Unstable voltage level
Signal integrity issues on
JTAG pins
Monitor related power supplies that cause
the issue during programming; check for
transients outside of Microsemi
specifications. See your device datasheet
for more information on transient
specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for
noise or reflection.
0x8032
5
Device is busy Unstable VDDIx voltage level
Monitor related power supplies that cause
the issue during programming; check for
transients outside of Microsemi
specifications. See your device datasheet
for more information on transient
specifications.
0x8003
5
Failed to enter
programming mode
Unstable voltage level
Signal integrity issues on
JTAG pins
DEVRST_N is tied to LOW
Monitor related power supplies that cause
the issue during programming; check for
transients outside of Microsemi
specifications. See your device datasheet
for more information on transient
specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for
noise or reflection.
Tie DEVRST_N to HIGH prior to
programming the device.
0x8004
6
Failed to verify IDCODE Incorrect programming file
Incorrect device in chain
Signal integrity issues on
JTAG pins
Choose the correct programming file and
select the correct device in the chain.
Measure JTAG pins and noise for
reflection. If TRST is left floating then add
pull-up to pin.
Reduce the length of Ground connection.
0x8005
0x8006
8x804A
10 Failed to program eNVM Unstable voltage level.
Signal integrity issues on
JTAG pins.
Monitor related power supplies that cause
the issue during programming; check for
transients outside of Microsemi
specifications. See your device datasheet
for more information on transient
specifications.
Monitor JTAG supply pins during
programming; measure JTAG signals for
noise or reflection.
