FlashPro Express User Guide
27
Running Tcl Scripts from the Command Line
You can run Tcl scripts from your Windows or Linux command line.
To execute a Tcl script file in the FlashPro Express software from a shell command line:
1.
At the prompt, type the path to the Microsemi software followed by the word "SCRIPT" and a colon, and then
the name of the script file as follows:
<location of Microsemi software>/bin/FPExpress.exe SCRIPT:<filename>
The example below executes in batch mode the script foo.tcl:
<location of Microsemi software>/bin/FPExpress.exe script:foo.tcl
The example below executes in batch mode the script foo.tcl and exports the log in the file foo.txt:
<location of Microsemi software>/bin/FPExpress.exe script:foo.tcl logfile:foo.txt
The example below executes in batch mode the script foo.tcl, creates a console where the log is
displayed briefly, and exports the log in the file foo.txt:
<location of Microsemi software>/bin/FPExpress.exe script:foo.tcl console_mode:brief
logfile:foo.txt
If you leave console_mode unspecified or set it to 'hide' FlashPro Express executes without a console
window. If you want to leave the console window open you can run the script with the console_mode
parameter set to 'show', as in the following example:
<location of Microsemi software>/bin/FPExpress.exe script:foo.tcl console_mode:show
logfile:foo.txt
2.
If you want to pass arguments to the Tcl script from the command line, then use the "SCRIPT_ARGS"
variable as follows:
<location of Microsemi software>/bin/FPExpress.exe SCRIPT:<filename> SCRIPT_ARGS:"param1
param2 param3"
Arguments passed to a Tcl script can be accessed through the Tcl variables argc and argv. The example
below demonstrates how a Tcl script accesses these arguments:
puts "Script name: $argv0"
puts "Number of arguments: $argc"
set i 0
foreach arg $argv {
puts "Arg $i : $arg"
incr i
}
Note: Script names can contain spaces if the script name is protected with double quotes:
FPExpress script:"FPExpress tcl/foo 1.tcl"
Exporting Tcl Scripts from within FlashPro Express
To export a set of Tcl commands from the FlashPro Express history:
1.
From the File menu, choose Export Script File.
2.
Enter the filename and click Save. The Export Script Options dialog appears (as shown in the figure below).
