Je bekijkt pagina 65 van 102
AC Switching Characteriscs
Data Sheet
© 2024 Microchip Technology Inc. and its subsidiaries
DS00003831E - 65
5.5.2 Interlaken
The following table describes Interlaken.
Table 5-48. Interlaken
Parameter Data Rate Min Max Unit
Total transmit jitter 6.375 Gbps — 0.3 UI
10.3125 Gbps — 0.3 UI
12.7 Gbps
1, 2
— 0.3 UI
Receiver jitter tolerance 6.375 Gbps 0.6 — UI
10.3125 Gbps 0.65 — UI
12.7 Gbps
1, 2
0.65 — UI
1. For data rates greater than 10.3125 Gbps, V
DDA
must be set to 1.05V mode. See supply tolerance
in the section Recommended Operating Conditions.
2. Supported on –1 speed grade only.
5.5.3 10GbE (10GBASE-R and 10GBASE-KR)
The following table describes 10GbE (10GBASE-R).
Table 5-49. 10GbE (10GBASE-R)
Parameter Data Rate Min Max Unit
Total transmit jitter 10.3125 Gbps — 0.28 UI
Receiver jitter tolerance 10.3125 Gbps 0.7 — UI
The following table describes 10GbE (10GBASE-KR).
Table 5-50. 10GbE (10GBASE-KR)
Parameter Data Rate Min Max Unit
Total transmit jitter 10.3125 Gbps — 0.28 UI
Receiver jitter tolerance (SJ) 10.3125 Gbps 0.115 — UI
Receiver jitter tolerance (RJ) 10.3125 Gbps 0.13 — UI
Receiver jitter tolerance (DCD) 10.3125 Gbps 0.035 — UI
The following table describes 10GbE (XAUI).
Table 5-51. 10GbE (XAUI)
Parameter Data Rate Min Max Unit
Total transmit jitter (near end) 3.125 Gbps — 0.35 UI
Total transmit jitter (far end) — — 0.55 UI
Receiver jitter tolerance 3.125 Gbps 0.65 — UI
The following table describes 10GbE (RXAUI).
Table 5-52. 10GbE (RXAUI)
Parameter Data Rate Min Max Unit
Total transmit jitter (near-end) 6.25 Gbps — 0.35 UI
Total transmit jitter (far-end) 6.25 Gbps — 0.55 UI
